Factory Default - Planet Networking & Communication GS-5220-24P4X User Manual

The page includes the following fields:
Object
• Image
• Version
• Date
Buttons

4.2.24 Factory Default

You can reset the configuration of the Managed Switch on this page. Only the IP configuration is retained. The new configuration
is available immediately, which means that no restart is necessary. The Factory Default screen in
Figure 4-2-28: Software Image Selection Page Screenshot
Description
The flash index name of the firmware image. The name of primary (preferred)
image is image, the alternate image is named image.bk.
The version of the firmware image.
The date when the firmware was produced.
: Click to use the alternate image. This button may be disabled depending on system state.
Figure 4-2-29: Factory Default Page Screenshot
User's Manual of GS-5220 Ultra PoE & PoE+ Series
96
Figure 4-2-29 appears.
