Planet Networking & Communication GS-5220-24P4X User Manual page 260

• Last Supplicant/Client
Info
Selected Counters
Object
• Selected Counters
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Information about the last supplicant/client that attempted to authenticate. This
information is available for the following administrative states:
■
Port-based 802.1X
■
Single 802.1X
■
Multi 802.1X
■
MAC-based Auth.
Name IEEE Name
MAC dot1xAuthLastEapolF
Address rameSource
VLAN ID -
Version dot1xAuthLastEapolF
rameVersion
Identity -
Description
The Selected Counters table is visible when the port is one of the following
administrative states:
■
Multi 802.1X
■
MAC-based Auth.
The table is identical to and is placed next to the Port Counters table, and will be empty if
260
for a given port (left-most
table) or client (right-most
table). Possible
retransmissions are not
counted.
Description
The MAC address of the last supplicant/client.
The VLAN ID on which the last frame from the
last supplicant/client was received.
802.1X-based:
The protocol version number carried in the most
recently received EAPOL frame.
MAC-based:
Not applicable.
802.1X-based:
The user name (supplicant identity) carried in the
most recently received Response Identity
EAPOL frame.
MAC-based:
Not applicable.
