Page 2: Fcc Warning
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Trademarks Copyright © PLANET Technology Corp. 2017. Contents are subject to revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for...
Page 3 User’s Manual of GS-5220 Ultra PoE & PoE+ Series TABLE OF CONTENTS 1. INTRODUCTION ........................10 1.1 Packet Contents ............................10 1.2 Product Description ........................... 12 1.3 How to Use This Manual ..........................18 1.4 Product Features ............................19 1.5 Product Specifications ..........................23 2.
Page 4 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.4 Users Configuration ............................. 74 4.2.5 Privilege Levels ..............................77 4.2.6 NTP Configuration ............................... 78 4.2.7 Time Configuration .............................. 79 4.2.8 UPnP ................................... 81 4.2.9 DHCP Relay ................................ 83 4.2.10 DHCP Relay Statistics ............................84 4.2.11 CPU Load ................................
Page 5 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.5 Link Aggregation ............................119 4.5.1 Static Aggregation .............................. 121 4.5.2 LACP Configuration ............................123 4.5.3 LACP System Status ............................124 4.5.4 LACP Port Status ............................... 125 4.5.5 LACP Port Statistics ............................126 4.6 VLAN ................................
Page 6 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.9 IGMPv3 Information ............................183 4.8.10 MLD Snooping Configuration ........................... 184 4.8.11 MLD Snooping VLAN Configuration ......................... 185 4.8.12 MLD Snooping Port Group Filtering ......................... 187 4.8.13 MLD Snooping Status ............................188 4.8.14 MLD Group Information ...........................
Page 7 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11.1 Understanding IEEE 802.1X Port-based Authentication .................. 240 4.11.2 Authentication Configuration ..........................243 4.11.3 Network Access Server Configuration ......................244 4.11.4 Network Access Overview ..........................255 4.11.5 Network Access Statistics ..........................256 4.11.6 RADIUS ................................
Page 8 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.15.2 IPv6 Ping ................................. 325 4.15.3 Remote IP Ping Test ............................326 4.15.4 Cable Diagnostics ............................327 4.16 Power over Ethernet ..........................329 4.16.1 Power over Ethernet Powered Device ......................329 4.16.2 System Configuration ............................
Page 9 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 6. TROUBLESHOOTING ....................... 362 APPENDIX A: Networking Connection ................363 A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T ............363 A.2 10/100Mbps, 10/100BASE-TX ........................363 APPENDIX B : GLOSSARY ....................365...
Page 10: Introduction
Ethernet copper and SFP/SFP+ fiber optic connectibility and robust Layer 2 and Layer 4 features. The descriptions of these models are shown below: Model Name Gigabit RJ45 Ports Gigabit SFP Slots PoE Ports 10G SFP+ Slots PoE Budget GS-5220-24P4X 4 combo GS-5220-24P4XR 4 combo GS-5220-24PL4X 4 combo GS-5220-24PL4XR 4 combo...
Page 11 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Model Name SFP Dust-proof Caps GS-5220-24P4X GS-5220-24P4XR GS-5220-24PL4X GS-5220-24PL4XR GS-5220-16UP4S2X GS-5220-16UP4S2XR GS-5220-24UP4X GS-5220-24UP4XR GS-5220-24UPL4X GS-5220-24UPL4XR If any of these are missing or damaged, please contact your dealer immediately; if possible, retain the carton including the...
Page 12: Product Description
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 1.2 Product Description Amazing Ultra PoE Managed Switch with Advanced L2+/L4 Switching and Security PLANET GS-5220 Ultra PoE & PoE+ Series is a Cost-optimized, 1U, Gigabit Ultra PoE Managed Switch featuring PLANET intelligent PoE functions to improve the availability of critical business applications.
Page 13 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Built-in Unique PoE Functions for Powered Devices Management As it is the managed PoE switch for surveillance, wireless and VoIP networks, the GS-5220 Ultra PoE & PoE+ Series features the following special PoE management functions: ...
Page 14 User’s Manual of GS-5220 Ultra PoE & PoE+ Series PoE Schedule for Energy Saving Under the trend of energy saving worldwide and contributing to environmental protection, the GS-5220 Ultra PoE & PoE+ Series can effectively control the power supply besides its capability of giving high watts power. The “PoE schedule” function helps you to enable or disable PoE power feeding for each PoE port during specified time intervals and it is a powerful function to help SMBs or enterprises save power and money.
Page 15 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Environment-friendly, Smart Fan Design for Silent Operation The GS-5220 Ultra PoE & PoE+ Series features a desktop-sized metal housing, a low noise design and an effective ventilation system. It supports the smart fan technology that automatically controls the speed of the built-in fan to reduce noise and maintain the temperature of the PoE switch for optimal power output capability.
Page 16 User’s Manual of GS-5220 Ultra PoE & PoE+ Series IPv4 and IPv6 VLAN Routing for Secure and Flexible Management To help customers stay on top of their businesses, the GS-5220 Ultra PoE & PoE+ Series not only provides ultra high transmission performance and excellent layer 2 technologies, but also offers IPv4/IPv6 VLAN routing feature which allows to cross over different VLANs and different IP addresses for the purpose of having a highly-secure, flexible management and simpler networking application.
Page 17 User’s Manual of GS-5220 Ultra PoE & PoE+ Series exible and Extendable Solution The 4 mini-GBIC SFP slots built in the GS-5220 Ultra PoE & PoE+ Series support dual speed as it features 100BASE-FX and 1000BASE-SX/LX SFP (Small Form-factor Pluggable) fiber-optic modules. Now the administrator can flexibly choose the suitable SFP transceiver according to not only the transmission distance, but also the transmission speed required.
Page 18: How To Use This Manual
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 1.3 How to Use This Manual This User’s Manual is structured as follows: Section 2, INSTALLATION The section explains the functions of the Managed Switch and how to physically install the Managed Switch. Section 3, SWITCH MANAGEMENT The section contains the information about the software function of the Managed Switch.
Page 19: Product Features
 Up to 16/24 ports of IEEE 802.3af/802.3at devices powered  Supports PoE Power up to 30.8 watts for each PoE port (GS-5220-24P4X/R and GS-5220-24PL4X/R)  Supports PoE Power up to 75 watts for each PoE port (GS-5220-16UP4S2X/R, 24UP4X/R and GS-5220-24UPL4X/R) ...
Page 20  Supports Link Aggregation − 802.3ad Link Aggregation Control Protocol (LACP) − Cisco ether-channel (Static Trunk) (GS-5220-24P4X/R, GS-5220-24PL4X/R, GS-5220-24UP4X/R and GS-5220-24UPL4X/R) − Maximum 14 trunk groups, up to 8 ports per trunk group − Up to 16Gbps bandwidth (full duplex mode) (GS-5220-16UP4S2X and GS-5220-16UP4S2XR) −...
Page 21 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Security  Authentication IEEE 802.1x Port-based/MAC-based network access authentication IEEE 802.1x Authentication with Guest VLAN Built-in RADIUS client to cooperate with the RADIUS servers RADIUS/TACACS+ users access authentication  Access Control List IP-based Access Control List (ACL) MAC-based Access Control List (ACL) ...
Page 22 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Redundant Power System (GS-5220-24P4XR, 24PL4XR, 16UP4S2XR, 24UP4XR and 24UPL4XR) ■ 100~240V AC/36-60V DC Dual power redundant ■ Active-active redundant power failure protection ■ Backup of catastrophic power failure on one supply ■...
Page 23: Product Specifications
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 1.5 Product Specifications GS-5220-24P4X and GS-5220-24P4XR Product GS-5220-24P4X GS-5220-24P4XR Hardware Specifications Copper Ports 24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports with IEEE 802.3at PoE injector 4 100/1000BASE-X SFP combo interfaces with Port-21 to Port-24...
Page 24 Dimensions (W x D x H) 440 x 300 x 44.5 mm, 1U height Enclosure Metal 3 x smart fan Weight 4546g (GS-5220-24P4X) 4570g (GS-5220-24P4XR) Layer 2 Function Port disable/enable Port Configuration Auto-negotiation 10/100/1000Mbps full or half duplex mode selection Flow control disable/enable Display each port’s speed duplex mode, link status, flow control status, auto-negotiation...
Page 25 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Layer 3 Function IP Interfaces Max. 8 VLAN interfaces Routing Table Max. 32 routing entries IPv4 software static routing Routing Protocols IPv6 software static routing Management Basic Management Console, Telnet, Web browser, and SNMP v1/v2c Interfaces Secure Management SSH/SSL, SNMP v3...
Page 26: Gs-5220-24Pl4Xr
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Environment Temperature: 0 ~ 50 degrees C Operating Relative Humidity: 5 ~ 95% (non-condensing) Temperature: -10 ~ 70 degrees C Storage Relative Humidity: 5 ~ 95% (non-condensing) GS-5220-24PL4X and GS-5220-24PL4XR Product GS-5220-24PL4X GS-5220-24PL4XR Hardware Specifications...
Page 27 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Power Pin Assignment 1/2(-), 3/6(+) PoE Power Budget 600 watts max. PD @ 7 watts 24 units PD @ 15.4 24 units PoE Ability watts PD @ 30.8 20 units watts 100~240V AC, 50/60Hz, 10A 100-240V AC, 50/60Hz, 10A Power...
Page 28 User’s Manual of GS-5220 Ultra PoE & PoE+ Series IGMP querier mode support MLD (v1/v2) snooping, up to 255 multicast groups MLD Snooping MLD querier mode support IP-based ACL / MAC-based ACL Access Control List Up to 256 entries Layer 3 Function IP Interfaces Max.
Page 29: Gs-5220-16Up4S2X
User’s Manual of GS-5220 Ultra PoE & PoE+ Series RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP v1 RFC 2236 IGMP v2 RFC 3376 IGMP v3 RFC 2710 MLD v1 FRC 3810 MLD v2 Environment Temperature: 0 ~ 50 degrees C for AC power input Operating Relative Humidity: 5 ~ 95% (non-condensing) Temperature: -40 ~ 80 degrees C...
Page 30 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 1000 (Green), 10G (Orange) Power Consumption Max. 439.4 watts/1498.3 BTU Power Requirements – AC AC 100~240V, 50/60Hz, 7A Power Requirements – DC DC 36~60V, 2A (GS-5220-16UP4S2X) 6KV DC ESD Protection 3 smart fan Power over Ethernet IEEE 802.3af/802.3at/802.3bt Ultra PoE PSE PoE Standard...
Page 31 User’s Manual of GS-5220 Ultra PoE & PoE+ Series MLD (v1/v2) snooping, up to 255 multicast groups MLD Snooping MLD querier mode support IP-based ACL/MAC-based ACL Access Control List Up to 256 entries Per port bandwidth control Bandwidth Control Ingress: 100Kbps~1000Mbps Egress: 100Kbps~1000Mbps Layer 3 Functions IP Interfaces...
Page 32: Gs-5220-24Up4X
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Environment Temperature: 0 ~ 50 degrees C for AC power input Operating Relative Humidity: 5 ~ 95% (non-condensing) Temperature: -40 ~ 80 degrees C Storage Relative Humidity: 5 ~ 95% (non-condensing) GS-5220-24UP4X and GS-5220-24UP4XR GS-5220-24UP4X and GS-5220-24UP4XR Product...
Page 33 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Power over Ethernet IEEE 802.3af/802.3at/802.3bt Ultra PoE PSE PoE Standard End-span/Mid-span/UPoE PoE Power Supply Type Per port 54V DC, 75 watts (max.) PoE Power Output End-span: 1/2(-), 3/6(+) Power Pin Assignment Mid-span: 4/5(+), 7/8(-) UPoE: 1/2(-), 3/6(+),4/5(+), 7/8(-) 400 watts (max.)
Page 34 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Layer 3 Functions IP Interfaces Max. 8 VLAN interfaces Routing Table Max. 32 routing entries IPv4 software static routing Routing Protocols IPv6 software static routing Management Basic Management Interfaces Console; Telnet; Web browser; SNMP v1, v2c Secure Management Interfaces SSH, SSL, SNMP v3 ONVIF device discovery...
Page 35: Gs-5220-24Upl4X
User’s Manual of GS-5220 Ultra PoE & PoE+ Series GS-5220-24UPL4X and GS-5220-24UPL4XR GS-5220-24UPL4X GS-5220-24UPL4XR Product Hardware Specifications 24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports Copper Ports 4 100/1000BASE-X SFP interfaces, shared with Port-21 to Port-24 SFP/mini-GBIC Slots Compatible with 100BASE-FX SFP transceiver 4 10GbBASE-SR/LR SFP+ interfaces (Port-25 to Port-28) SFP+ Slots Compatible with 1000BASE-SX/LX/BX SFP transceiver...
Page 36 User’s Manual of GS-5220 Ultra PoE & PoE+ Series UPoE: 1/2(-), 3/6(+),4/5(+), 7/8(-) 600 watts (max.) PoE Power Budget 24 units PoE Ability PD @ 15 watts 20 units PoE Ability PD @ 30 watts 10 units PoE Ability PD @ 60 watts Layer 2 Management Functions Port disable/enable Port Configuration...
Page 37 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Management Basic Management Interfaces Console; Telnet; Web browser; SNMP v1, v2c Secure Management Interfaces SSH, SSL, SNMP v3 ONVIF device discovery ONVIF ONVIF device monitoring Floor map RFC 1213 MIB-II RFC 1493 Bridge MIB RFC 1643 Ethernet MIB RFC 2863 Interface MIB RFC 2665 Ether-Like MIB...
Page 38 User’s Manual of GS-5220 Ultra PoE & PoE+ Series RFC 2236 IGMP v2 RFC 3376 IGMP v3 RFC 2710 MLD v1 FRC 3810 MLD v2 Environment Temperature: 0 ~ 50 degrees C for AC power input Operating Relative Humidity: 5 ~ 95% (non-condensing) Temperature: -40 ~ 80 degrees C Storage Relative Humidity: 5 ~ 95% (non-condensing)
Page 39: Hardware Description
The front panel provides a simple interface monitoring the Managed Switch. Figures 2-1-1 to 2-1-10 show the front panels of the Managed Switches. GS-5220-24P4X Front Panel Figure 2-1-1: Front Panel of GS-5220-24P4X GS-5220-24P4XR Front Panel Figure 2-1-2: Front Panel of GS-5220-24P4XR GS-5220-24PL4X Front Panel Figure 2-1-3: Front Panel of GS-5220-24PL4X...
Page 40 User’s Manual of GS-5220 Ultra PoE & PoE+ Series GS-5220-16UP4S2X Front Panel Figure 2-1-5: Front Panel of GS-5220-16UP4S2X GS-5220-16UP4S2XR Front Panel Figure 2-1-6: Front Panel of GS-5220-16UP4S2X GS-5220-24UP4X Front Panel Figure 2-1-7: Front Panel of GS-5220-24UP4X GS-5220-24UP4XR Front Panel Figure 2-1-8: Front Panel of GS-5220-24UP4XR GS-5220-24UPL4X Front Panel Figure 2-1-9: Front Panel of GS-5220-24UPL4X GS-5220-24UPL4XR Front Panel...
Page 41 User’s Manual of GS-5220 Ultra PoE & PoE+ Series GS-5220-48P(L)4X Front Panel Figure 2-1-11: Front Panel of GS-5220-48P(L)4X GS-5220-48P(L)4XR Front Panel Figure 2-1-12: Front Panel of GS-5220-48P(L)4XR ■ Gigabit TP interface 10/100/1000BASE-T Copper, RJ45 twisted-pair: Up to 100 meters. ■ SFP slot 100/1000BASE-X mini-GBIC slot, SFP (Small Factor Pluggable) transceiver module: From 550 meters to 2km (multi-mode fiber), up to above 10/20/30/40/50/70/120 kilometers (single-mode fiber).
Page 42: Led Indications
Figures 2-1-11 to 2-1-20 show the LED indications of the Managed Switches. GS-5220-24P4X / GS-5220-24P4XR LED Indication Figure 2-1-13: GS-5220-24P4X LED on Front Panel Figure 2-1-14: GS-5220-24P4XR LED on Front Panel  System / Alert (GS-5220-24P4X) Color...
Page 43 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  10/100/1000BASE-T Interfaces (Port-1 to Port-24) Color Function Lights: To indicate that the port is operating at 1000Mbps. Green Blinks: To indicate that the switch is actively sending or receiving data over that port. Ethernet Lights: To indicate that the port is operating at 10/100Mbps.
Page 44 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  System / Alert (GS-5220-24PL4X) Color Function Green Lights to indicate that the Switch has power. Lights to indicate the system is working. Green Off to indicate the system is booting. FAN 1 Lights to indicate that FAN1 is down.
Page 45 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  1/10GBASE-SR/LR SFP+ Interfaces (Port-25 to Port-28) Color Function To indicate that the port is operating at 10Gbps. Lights: Orange Blinks: To indicate that the switch is actively sending or receiving data over that port. Lights: To indicate that the port is operating at 1000Mbps.
Page 46 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  10/100/1000BASE-T Interfaces (Port-1 to Port-16) Color Function To indicate that the port is operating at 1000Mbps. Lights: Green Blinks: To indicate that the switch is actively sending or receiving data over that port. Ethernet Lights: To indicate that the port is operating at 10/100Mbps.
Page 47 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  System / Alert (GS-5220-24UP4X) Color Function Lights to indicate that the Switch has power. Green Lights to indicate the system is working. Green Off to indicate the system is booting. FAN 1 Lights to indicate that FAN1 is down.
Page 48 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  1/10GBASE-SR/LR SFP+ Interfaces (Port-25 to Port-28) Color Function To indicate that the port is operating at 10Gbps. Lights: Orange Blinks: To indicate that the switch is actively sending or receiving data over that port. Lights: To indicate that the port is operating at 1000Mbps.
Page 49 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  10/100/1000BASE-T Interfaces (Port-1 to Port-24) Color Function Lights: To indicate that the port is operating at 1000Mbps. Green Blinks: To indicate that the switch is actively sending or receiving data over that port. Ethernet Lights: To indicate that the port is operating at 10/100Mbps.
Page 50 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 2-1-24: GS-5220- GS-5220-48P(L)4XR LED on Front Panel  System/Alert (GS-5220-48P4X/GS-5220-48PL4X) Color Function Green Lights to indicate that the Switch has power. Lights to indicate the system is working. Green Off to indicate the system is booting. FAN 1 Lights to indicate that FAN1 is down.
Page 51: Switch Rear Panel
Figures 2-1-21 to 2-1-22 show the rear panels of the Managed Switches. GS-5220-24P4X/24PL4X/16UP4S2X/24UP4X/24UPL4X/48P4X/48PL4XR Rear Panel Figure 2-1-25: Rear Panel of GS-5220-24P4X/24PL4X/16UP4S2X/24UP4X/24UPL4X/48P4X/48PL4X GS-5220-24P4XR/24PL4XR/16UP4S2XR/24UP4XR/24UPL4XR/48P4XR/48PL4XR Rear Panel Figure 2-1-26: Rear Panel of GS-5220-24P4XR/24PL4XR/16UP4S2XR/24UP4XR/24UPL4XR/48P4XR/48PL4XR ■ AC Power Receptacle For compatibility with electrical voltages in most areas of the world, the Managed Switch’s power supply can automatically adjust line power in the range of 100-240V AC and 50/60 Hz.
Page 52 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ DC Power Connector The following GS-5220 series supports redundant power system (PoE not included ):  GS-5220-24P4XR  GS-5220-24PL4XR  GS-5220-16UP4S2XR  GS-5220-24UP4XR  GS-5220-24UPL4XR The rear panels of the above models have a power switch and a DC power connector, where the latter accepts DC power input voltage from 36V to 60V DC.
Page 53: Installing The Switch
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 2.2 Installing the Switch This section describes how to install your Managed Switch and make connections to the Managed Switch. Please read the following topics and perform the procedures in the order being presented. To install your Managed Switch on a desktop or shelf, simply complete the following steps.
Page 54: Rack Mounting
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 2.2.2 Rack Mounting To install the Managed Switch in a 19-inch standard rack, please follow the instructions described below. Step 1: Place the Managed Switch on a hard flat surface, with the front panel positioned towards the front side. Step 2: Attach the rack-mount bracket to each side of the Managed Switch with supplied screws attached to the package.
Page 55: Installing The Sfp/Sfp+ Transceiver
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Step 6: Proceed with Steps 4 and 5 of session 2.2.1 Desktop Installation to connect the network cabling and supply power to the Managed Switch. 2.2.3 Installing the SFP/SFP+ Transceiver The sections describe how to insert an SFP/SFP+ transceiver into an SFP/SFP+ slot. The SFP/SFP+ transceivers are hot-pluggable and hot-swappable.
Page 56 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Fast Ethernet Transceiver (100BASE-BX, Single Fiber Bi-directional SFP) Model Speed (Mbps) Connector Interface Fiber Mode Distance Wavelength (TX/RX) Operating Temp. MFB-FA20 WDM(LC) Single Mode 20km 1310nm/1550nm 0 ~ 60 degrees C MFB-FB20 WDM(LC) Single Mode...
Page 57 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 10Gbps SFP+ (10G Ethernet/10GBASE) Connector Model Speed (Mbps) Fiber Mode Distance Wavelength (nm) Operating Temp. Interface MTB-SR Multi Mode Up to 300m 850nm 0 ~ 60 degrees C MTB-LR Single Mode 10km 1310nm 0 ~ 60 degrees C...
Page 58 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Remove the Transceiver Module Make sure there is no network activity anymore. Remove the Fiber-Optic Cable gently. Lift up the lever of the MGB module and turn it to a horizontal position. Pull out the module gently through the lever.
Page 59: Switch Management
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 3. SWITCH MANAGEMENT This chapter explains the methods that you can use to configure management access to the Managed Switch. It describes the types of management applications and the communication and management protocols that deliver data between your management device (workstation or personal computer) and the system.
Page 60: Management Access Overview
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 3.2 Management Access Overview The Managed Switch gives you the flexibility to access and manage it using any or all of the following methods:  An administration console  Web browser interface ...
Page 61: Administration Console
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 3.3 Administration Console The administration console is an internal, character-oriented, and command line user interface for performing system administration such as displaying statistics or changing option settings. Using this method, you can view the administration console from a terminal, personal computer, Apple Macintosh, or workstation connected to the Managed Switch's console (serial) port.
Page 62: Web Management
User’s Manual of GS-5220 Ultra PoE & PoE+ Series You can change these settings, if desired, after you log on. This management method is often preferred because you can remain connected and monitor the system during system reboots. Also, certain error messages are sent to the serial port, regardless of the interface through which the associated action was initiated.
Page 63: Planet Smart Discovery Utility
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 3.5 SNMP-based Network Management You can use an external SNMP-based application to configure and manage the Managed Switch, such as SNMP Network Manager, HP Openview Network Node Management (NNM) or What’s Up Gold. This management method requires the SNMP agent on the switch and the SNMP Network Management Station to use the same community string.
Page 64 User’s Manual of GS-5220 Ultra PoE & PoE+ Series If there are two LAN cards or above in the same administrator PC, choose a different LAN card by using the “Select Adapter” tool. Press the “Refresh” button for the currently connected devices in the discovery list as the screen shows below: Figure 3-1-7: Planet Smart Discovery Utility Screen This utility shows all necessary information from the devices, such as MAC address, device name, firmware version, and device IP subnet address.
Page 65: Web Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4. WEB CONFIGURATION This section introduces the configuration and functions of the Web-based management from Managed Switch. About Web-based Management The Managed Switch offers management features that allow users to manage the Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.
Page 66 User’s Manual of GS-5220 Ultra PoE & PoE+ Series When the following login screen appears, please enter the default username "admin" with password “admin” (or the username/password you have changed via console) to login the main screen of Managed Switch. The login screen in Figure 4-1-2 appears.
Page 67: Main Web Page
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Now, you can use the Web management interface to continue the switch management or manage the Managed Switch by Web interface. The Switch Menu on the left of the web page lets you access all the commands and statistics the Managed Switch provides.
Page 68 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Main Menu Using the onboard web agent, you can define system parameters, manage and control the Managed Switch, and all its ports, or monitor network conditions. Via the Web-Management, the administrator can set up the Managed Switch by selecting the functions those listed in the Main Function.
Page 69: System
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2 System Use the System menu items to display and configure basic administrative details of the Managed Switch. Under the System, the following topics are provided to configure and view the system information. This section has the following items: ■...
Page 70: System Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.1 System Information The System Infomation page provides information for the current device information. System Information page helps a switch administrator to identify the hardware MAC address, software version and system uptime. The screen in Figure 4-2-1 appears.
Page 71: Ip Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.2 IP Configuration The IP Configuration includes the IP Configuration, IP Interface and IP Routes. The configured column is used to view or change the IP configuration. The maximum number of interfaces supported is 128 and the maximum number of routes is 32. The screen in Figure 4-2-2 appears.
Page 72 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Specify from which DHCP-enabled interface a provided DNS server should be preferred. When DNS proxy is enabled, system will relay DNS requests to the DNS Proxy currently configured DNS server, and reply as a DNS resolver to the client devices on the network.
Page 73: Ip Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.3 IP Status IP Status displays the status of the IP protocol layer. The status is defined by the IP interfaces, the IP routes and the neighbor cache (ARP cache) status. The screen in Figure 4-2-3 appears.
Page 74: Users Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.4 Users Configuration This page provides an overview of the current users. Currently the only way to login as another user on the web server is to close and reopen the browser. After setup is completed, press the “Apply” button to take effect. Please login web interface with new user name and password;...
Page 75 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-2-5: Add / Edit User Configuration Page Screenshot The page includes the following fields: Object Description • Username A string identifying the user name that this entry should belong to. The allowed string length is 1 to 31.
Page 76 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Once the new user is added, the new user entry is shown on the Users Configuration page. Figure 4-2-6: User Configuration Page Screenshot If you forget the new password after changing the default password, please press the “Reset” button on the front panel of the Managed Switch for over 10 seconds and then release it.
Page 77: Privilege Levels
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.5 Privilege Levels This page provides an overview of the privilege levels. After setup is completed, please press the “Apply” button to take effect. Please login web interface with new user name and password and the screen in Figure 4-2-7 appears.
Page 78: Ntp Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Security: Authentication, System Access Management, Port (contains Dot1x port, MAC based and the MAC Address Limit), ACL, HTTPS, SSH, ARP Inspection and IP source guard.  IP: Everything except 'ping'. ...
Page 79: Time Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Mode Indicates the NTP mode operation. Possible modes are:  Enabled: Enable NTP mode operation. When enabling NTP mode operation, the agent forward and transfer NTP messages between the clients and the server when they are not on the same subnet domain.
Page 80 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-2-9: Time Configuration Page Screenshot The page includes the following fields: Object Description • Time Zone Lists various Time Zones worldwide. Select appropriate Time Zone from the drop-down and click Save to set. •...
Page 81: Upnp
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Month - Select the starting month. • Hours - Select the starting hour. • Minutes - Select the starting minute. • End Time Settings • Week - Select the ending week number. •...
Page 82 User’s Manual of GS-5220 Ultra PoE & PoE+ Series When the mode is enabled, two ACEs are added automatically to trap UPnP related packets to CPU. The ACEs are automatically removed when the mode is disabled. • TTL The TTL value is used by UPnP to send SSDP advertisement messages. Valid values are in the range of 1 to 255.
Page 83: Dhcp Relay
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.9 DHCP Relay Configure DHCP Relay on this page. DHCP Relay is used to forward and transfer DHCP messages between the clients and the server when they are not on the same subnet domain. The DHCP option 82 enables a DHCP relay agent to insert specific information into a DHCP request packets when forwarding client DHCP packets to a DHCP server and remove the specific information from a DHCP reply packets when forwarding server DHCP packets to a DHCP client.
Page 84: Dhcp Relay Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Relay Information Indicates the DHCP relay information mode option operation. Possible modes Mode are:  Enabled: Enable DHCP relay information mode operation. When enabling DHCP relay information mode operation, the agent inserts specific information (option82) into a DHCP message when forwarding to DHCP server and removing it from a DHCP message when transferring to DHCP client.
Page 85 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Server Statistics Object Description • Transmit to Server The packets number that relayed from client to server. • Transmit Error The packets number that erroneously sent packets to clients. •...
Page 86: Cpu Load
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.11 CPU Load This page displays the CPU load, using an SVG graph. The load is measured as average over the last 100ms, 1 sec and 10 seconds intervals. The last 120 samples are graphed, and the last numbers are displayed as text as well. In order to display the SVG graph, your browser must support the SVG format.
Page 87: System Log
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.12 System Log The Managed Switch system log information is provided here. The System Log screen in Figure 4-2-15 appears. Figure 4-2-15: System Log Page Screenshot The page includes the following fields: Object Description •...
Page 88: Detailed Log
User’s Manual of GS-5220 Ultra PoE & PoE+ Series : Updates the system log entries, starting from the first available entry ID. : Updates the system log entries, ending at the last entry currently displayed. : Updates the system log entries, starting from the last entry currently displayed. : Updates the system log entries, ending at the last available entry ID.
Page 89: Remote Syslog
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.14 Remote Syslog Configure remote syslog on this page. The Remote Syslog screen in Figure 4-2-17 appears. Figure 4-2-17: Remote Syslog Page Screenshot The page includes the following fields: Object Description •...
Page 90: Smtp Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.15 SMTP Configuration This page facilitates an SMTP Configuration on the switch. The SMTP Configure screen in Figure 4-2-18 appears. Figure 4-2-18: SMTP Configuration Page Screenshot The page includes the following fields: Object Description •...
Page 91: Web Firmware Upgrade
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.16 Web Firmware Upgrade This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-19 appears. Figure 4-2-19: Web Firmware Upgrade Page Screenshot To open Firmware Upgrade screen, perform the following: Click System ->...
Page 92: Tftp Firmware Upgrade
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.17 TFTP Firmware Upgrade The Firmware Upgrade page provides the functions to allow a user to update the Managed Switch firmware from the TFTP server in the network. Before updating, make sure you have your TFTP server ready and the firmware image is on the TFTP server.
Page 93: Save Startup Config
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.18 Save Startup Config This function allows to save the current configuration, thereby ensuring that the current active configuration can be used at the next reboot as the screen in Figure 4-2-22 appears.
Page 94: Configuration Upload
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.2.20 Configuration Upload Configuration Upload page allows the upload the running-config and startup-config on the switch. Please refer to the Figure 4-2-25 shown below. Figure 4-2-25: Configuration Upload Page Screenshot If the destination is running-config, the file will be applied to the switch configuration. This can be done in two ways: •...
Page 95: Image Select
User’s Manual of GS-5220 Ultra PoE & PoE+ Series It is possible to activate any of the configuration files present on the switch, except for running-config which represents the currently active configuration. Select the file to activate and click . This will initiate the process of completely replacing the existing configuration with that of the selected file.
Page 96: Factory Default
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-2-28: Software Image Selection Page Screenshot The page includes the following fields: Object Description • Image The flash index name of the firmware image. The name of primary (preferred) image is image, the alternate image is named image.bk. •...
Page 97: System Reboot
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to reset the configuration to Factory Defaults. : Click to return to the Port State page without resetting the configuration. To reset the Managed Switch to the Factory default setting, you can also press the hardware reset button at the front panel about 10 seconds.
Page 98: Simple Network Management Protocol
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.3 Simple Network Management Protocol 4.3.1 SNMP Overview The Simple Network Management Protocol (SNMP) is an application layer protocol that facilitates the exchange of management information between network devices. It is part of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suite. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth.
Page 99: Snmp System Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series SNMP community An SNMP community is the group that devices and management stations running SNMP belong to. It helps define where information is sent. The community name is used to identify the group. An SNMP device or agent may belong to more than one SNMP community.
Page 100 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  SNMP v2c: Set SNMP supported version 2c.  SNMP v3: Set SNMP supported version 3. • Read Community Indicates the community read access string to permit access to SNMP agent. The allowed string length is 0 to 255, and the allowed content is the ASCII characters from 33 to 126.
Page 101: Snmp Trap Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.3.3 SNMP Trap Configuration Configure SNMP trap on this page. The SNMP Trap Configuration screen in Figure 4-3-2 appears. Figure 4-3-2: SNMP Trap Configuration Page Screenshot The page includes the following fields: Object Description •...
Page 102 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  SNMP v1: Set SNMP trap supported version 1.  SNMP v2c: Set SNMP trap supported version 2c.  SNMP v3: Set SNMP trap supported version 3. • Trap Community Indicates the community access string when send SNMP trap packet. The allowed string length is 0 to 255, and the allowed content is the ASCII characters from 33 to 126.
Page 103: Snmp System Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Switch Indicates that the Switch group's traps. Possible traps are:  STP: Enable/disable STP trap.  RMON: Enable/disable RMON trap. Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. 4.3.4 SNMP System Information The switch system information is provided here.
Page 104: Snmpv3 Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.3.5 SNMPv3 Configuration 4.3.5.1 SNMPv3 Communities Configure SNMPv3 communities table on this page. The entry index key is Community. The SNMPv3 Communities screen in Figure 4-3-4 appears. Figure 4-3-4: SNMPv3 Communities Configuration Page Screenshot The page includes the following fields: Object Description...
Page 105: Snmpv3 Users
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.3.5.2 SNMPv3 Users Configure SNMPv3 users table on this page. The entry index keys are Engine ID and User Name. The SNMPv3 Users screen in Figure 4-3-5 appears. Figure 4-3-5: SNMPv3 Users Configuration Page Screenshot The page includes the following fields: Object Description...
Page 106: Snmpv3 Groups
User’s Manual of GS-5220 Ultra PoE & PoE+ Series  MD5: An optional flag to indicate that this user using MD5 authentication protocol.  SHA: An optional flag to indicate that this user using SHA authentication protocol. The value of security level cannot be modified if entry already exist. That means must first ensure that the value is set correctly.
Page 107: Snmpv3 Views
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Delete Check to delete the entry. It will be deleted during the next save. • Indicates the security model that this entry should belong to. Possible security Security Model models are: ...
Page 108: Snmpv3 Access
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Delete Check to delete the entry. It will be deleted during the next save. • A string identifying the view name that this entry should belong to. The allowed View Name string length is 1 to 32, and the allowed content is the ASCII characters from 33 to 126.
Page 109 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Delete Check to delete the entry. It will be deleted during the next save. • A string identifying the group name that this entry should belong to. The allowed Group Name string length is 1 to 32, and the allowed content is the ASCII characters from 33 to 126.
Page 110: Port Management
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.4 Port Management Use the Port Menu to display or configure the Managed Switch's ports. This section has the following items:  Port Configuration Configures port connection settings  Port Statistics Overview Lists Ethernet and RMON port statistics ...
Page 111 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Select any available link speed for the given switch port. Draw the menu bar to Configured Link Speed select the mode.  Auto – Set up Auto negotiation for copper interface. ...
Page 112: Port Statistics Overview
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.4.2 Port Statistics Overview This page provides an overview of general traffic statistics for all switch ports. The Port Statistics Overview screen in Figure 4-4-2 appears. Figure 4-4-2: Port Statistics Overview Page Screenshot The displayed counters are: Object Description...
Page 113: Detailed Port Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.4.3 Detailed Port Statistics This page provides detailed traffic statistics for a specific switch port. Use the port select box to select which switch port details to display. The displayed counters are the totals for receive and transmit, the size counters for receive and transmit, and the error counters for receive and transmit.
Page 114 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Receive and Transmit Size Counters The number of received and transmitted (good and bad) packets split into categories based on their respective frame sizes. Receive and Transmit Queue Counters The number of received and transmitted packets per input and output queue. Receive Error Counters Object Description...
Page 115: Sfp Module Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.4.4 SFP Module Information The WGSW-48040HP has supported the SFP module with digital diagnostics monitoring (DDM) function. This feature is also known as digital optical monitoring (DOM). You can check the physical or operational status of an SFP module via the SFP Module Information page.
Page 116: Port Mirror
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Current(mA) Display the Ampere of current SFP DDM module; the Ampere value is got from – SFP DDM Module Only the SFP DDM module. • TX power (dBm) Display the TX power of current SFP DDM module; the TX power value is got –...
Page 117 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-4-7: Port Mirror Application The traffic to be copied to the mirror port is selected as follows: • All frames received on a given port (also known as ingress or source mirroring). •...
Page 118 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Port to mirror on Frames from ports that have either source (rx) or destination (tx) mirroring enabled are mirrored to this port. Disabled disables mirroring. •...
Page 119: Link Aggregation
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.5 Link Aggregation Port Aggregation optimizes port usage by linking a group of ports together to form a single Link Aggregated Groups (LAGs). Port Aggregation multiplies the bandwidth between the devices, increases port flexibility, and provides link redundancy. Each LAG is composed of ports of the same speed, set to full-duplex operations.
Page 120 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems that require high speed redundant links. Link aggregation lets you group up to eight consecutive ports into a single dedicated connection.
Page 121: Static Aggregation
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.5.1 Static Aggregation This page is used to configure the Aggregation hash mode and the aggregation group. The aggregation hash mode settings are global. Hash Code Contributors The Static Aggregation screen in Figure 4-5-2 appears.
Page 122 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-5-3: Aggregation Group Configuration Page Screenshot The page includes the following fields: .Object Description • Indicates the group ID for the settings contained in the same row. Group ID Group ID "Normal"...
Page 123: Lacp Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.5.2 LACP Configuration Link Aggregation Control Protocol (LACP) - LACP LAG negotiate Aggregated Port links with other LACP ports located on a different device. LACP allows switches connected to each other to discover automatically whether any ports are member of the same LAG.
Page 124: Lacp System Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Timeout The Timeout controls the period between BPDU transmissions. Fast will transmit LACP packets each second, while Slow will wait for 30 seconds before sending a LACP packet. • Priority The Priority controls the priority of the port.
Page 125: Lacp Port Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to refresh the page immediately. Auto-refresh : Automatic refresh occurs every 3 seconds. 4.5.4 LACP Port Status This page provides a status overview of LACP status for all ports. The LACP Port Status screen in Figure 4-5-6 appears.
Page 126: Lacp Port Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.5.5 LACP Port Statistics This page provides an overview of LACP statistics for all ports. The LACP Port Statistics screen in Figure 4-5-7 appears. Figure 4-5-7: LACP Statistics Page Screenshot The page includes the following fields: Object Description •...
Page 127: Vlan Overview
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6 VLAN 4.6.1 VLAN Overview A Virtual Local Area Network (VLAN) is a network topology configured according to a logical scheme rather than the physical layout. VLAN can be used to combine any collection of LAN segments into an autonomous user group that appears as a single LAN.
Page 128: Ieee 802.1Q Vlan
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6.2 IEEE 802.1Q VLAN In large networks, routers are used to isolate broadcast traffic for each subnet into separate domains. This Managed Switch provides a similar service at Layer 2 by using VLANs to organize any group of network nodes into separate broadcast domains. VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks.
Page 129 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ 802.1Q VLAN Tags The figure below shows the 802.1Q VLAN tag. There are four additional octets inserted after the source MAC address. Their presence is indicated by a value of 0x8100 in the Ether Type field. When a packet's Ether Type field is equal to 0x8100, the packet carries the IEEE 802.1Q/802.1p tag.
Page 130 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Every physical port on a switch has a PVID. 802.1Q ports are also assigned a PVID, for use within the switch. If no VLAN are defined on the switch, all ports are then assigned to a default VLAN with a PVID equal to 1. Untagged packets are assigned the PVID of the port on which they were received.
Page 131: Vlan Port Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Port Overlapping Port overlapping can be used to allow access to commonly shared network resources among different VLAN groups, such as file servers or printers. Note that if you implement VLANs which do not overlap, but still need to communicate, you can connect them by enabled routing on this switch.
Page 132 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ IEEE 802.1Q Tunneling (Q-in-Q) IEEE 802.1Q Tunneling (Q-in-Q) is designed for service providers carrying traffic for multiple customers across their networks. Q-in-Q tunneling is used to maintain customer-specific VLAN and Layer 2 protocol configurations even when different customers use the same internal VLAN IDs.
Page 133 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Global VLAN Configuration The Global VLAN Configuration screen in Figure 4-6-1 appears. Figure 4-6-1 : Global VLAN Configuration Screenshot The page includes the following fields: Object Description • This field shows the allowed Access VLANs, it only affects ports configured as Allowed Access VLANs Access ports.
Page 134 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-6-2 : Port VLAN Configuration Screenshot The page includes the following fields: Object Description • Port This is the logical port number for this row. • Mode Access Access ports are normally used to connect to end stations. Dynamic features like Voice VLAN may add the port to more VLANs behind the scenes.
Page 135 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Tagging configuration is set to untag Port VLAN. The Port VLAN is called an "Access VLAN" for ports in Access mode and Native VLAN for ports in Trunk or Hybrid mode. •...
Page 136 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Untagged Only Only untagged frames are accepted on ingress. Tagged frames are discarded. Egress Tagging This option is only available for ports in Hybrid mode. Ports in Trunk and Hybrid mode may control the tagging of frames on egress.
Page 137: Vlan Membership Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6.4 VLAN Membership Status This page provides an overview of membership status for VLAN users. The VLAN Membership Status screen in Figure 4-6-4 appears. Figure 4-6-4: VLAN Membership Status for Static User Page Screenshot The page includes the following fields: Object Description...
Page 138: Vlan Port Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series a Combo Box). When ALL VLAN Users are selected, it shall show this information for all the VLAN Users, and this is by default. VLAN membership allows the frames classified to the VLAN ID to be forwarded on the respective VLAN member ports.
Page 139 User’s Manual of GS-5220 Ultra PoE & PoE+ Series on the port. VLAN tagged frames are classified to the VLAN ID in the tag. If VLAN awareness is disabled, all frames are classified to the Port VLAN ID and tags are not removed. •...
Page 140: Port Isolation
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6.6 Port Isolation Overview When a VLAN is configured to be a private VLAN, communication between ports within that VLAN can be prevented. Two application examples are provided in this section: •...
Page 141 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The configuration of promiscuous and isolated ports applies to all private VLANs. When traffic comes in on a promiscuous port in a private VLAN, the VLAN mask from the VLAN table is applied. When traffic comes in on an isolated port, the private VLAN mask is applied in addition to the VLAN mask from the VLAN table.
Page 142: Vlan Setting Example
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6.7 VLAN setting example:  Separate VLAN  802.1Q VLAN Trunk  Port Isolate 4.6.7.1 Two Separate 802.1Q VLANs The diagram shows how the Managed Switch handle Tagged and Untagged traffic flow for two VLANs. VLAN Group 2 and VLAN Group 3 are separated VLAN.
Page 143 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The scenario is described as follows:  Untagged packet entering VLAN 2 While [PC-1] transmit an untagged packet enters Port-1, the Managed Switch will tag it with a VLAN Tag=2. [PC-2] and [PC-3] will received the packet through Port-2 and Port-3. [PC-4],[PC-5] and [PC-6] received no packet.
Page 144: Vlan Trunking Between Two 802.1Q Aware Switches
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-6-9: Change Port VLAN of Port 1~3 to be VLAN2 and Port VLAN of Port 4~6 to be VLAN3 Enable VLAN Tag for specific ports Link Type: Port-3 (VLAN-2) and Port-6 (VLAN-3) Change Port 3 Mode as Trunk, Selects Egress Tagging as Tag All and Types 2 in the Allowed VLANs column.
Page 145 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-6-11: VLAN Trunking Diagram Setup steps Add VLAN Group Add two VLANs – VLAN 2 and VLAN 3 Type 1-3 in Allowed Access VLANs column, the 1-3 is including VLAN1 and 2 and 3. Figure 4-6-12: Add VLAN 2 and VLAN 3 Assign VLAN Member and PVID for each port : VLAN 2 : Port-1,Port-2 and Port-3...
Page 146 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-6-13: Changes Port VLAN of Port 1~3 to be VLAN2 and Port VLAN of Port 4~6 to be VLAN3 For the VLAN ports connecting to the hosts, please refer to 4.6.10.1 examples. The following steps will focus on the VLAN Trunk port configuration.
Page 147: Port Isolate
User’s Manual of GS-5220 Ultra PoE & PoE+ Series That is, although the VLAN 2 members: Port-1 to Port-3 and VLAN 3 members: Port-4 to Port-6 also belongs to VLAN 1. But with different PVID settings, packets form VLAN 2 or VLAN 3 is not able to access to the other VLAN. Repeat Steps 1 to 6, set up the VLAN Trunk port at the partner switch and add more VLANs to join the VLAN trunk, repeat Steps 1 to 3 to assign the Trunk port to the VLANs.
Page 148: Mac-Based Vlan
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6.8 MAC-based VLAN The MAC-based VLAN entries can be configured here. This page allows for adding and deleting MAC-based VLAN entries and assigning the entries to different ports. This page shows only static entries. The MAC-based VLAN screen in Figure 4-6-18 appears.
Page 149: Protocol-Based Vlan
User’s Manual of GS-5220 Ultra PoE & PoE+ Series : Click to undo any changes made locally and revert to previously saved values. Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. : Click to refresh the page immediately. : Updates the table starting from the first entry in the MAC-based VLAN Table.
Page 150 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Value Valid value that can be entered in this text field depends on the option selected from the preceding Frame Type selection menu. Below is the criteria for three different Frame Types: For Ethernet: Values in the text field when Ethernet is selected as a Frame Type is called etype.
Page 151: Protocol-Based Vlan Membership
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.6.10 Protocol-based VLAN Membership This page allows you to map a already configured Group Name to a VLAN for the switch. The Group Name to VLAN Mapping Table screen in Figure 4-6-20 appears.
Page 152: Spanning Tree Protocol
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.7 Spanning Tree Protocol 4.7.1 Theory The Spanning Tree protocol can be used to detect and disable network loops, and to provide backup links between switches, bridges or routers. This allows the switch to interact with other bridging devices in your network to ensure that only one route exists between any two stations on the network, and provide backup links which automatically take over when a primary link goes down.
Page 153 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  The path cost to the root from the transmitting port  The port identifier of the transmitting port The switch sends BPDUs to communicate and construct the spanning-tree topology. All switches connected to the LAN on which the packet is transmitted will receive the BPDU.
Page 154 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  From forwarding to disabled  From disabled to blocking Figure 4-7-1: STP Port State Transitions You can modify each port state by using management software. When you enable STP, every port on every switch in the network goes through the blocking state and then transitions through the states of listening and learning at power up.
Page 155 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The following are the user-configurable STP parameters for the switch level: Parameter Description Default Value Bridge Identifier(Not user A combination of the User-set priority and 32768 + MAC configurable the switch’s MAC address. The Bridge Identifier consists of two parts: except by setting priority a 16-bit priority and a 48-bit Ethernet MAC...
Page 156 User’s Manual of GS-5220 Ultra PoE & PoE+ Series User-Changeable STA Parameters The Switch’s factory default setting should cover the majority of installations. However, it is advisable to keep the default settings as set at the factory; unless, it is absolutely necessary. The user changeable parameters in the Switch are as follows: Priority –...
Page 157 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-7-2: Before Applying the STA Rules In this example, only the default STP values are used. Figure 4-7-3: After Applying the STA Rules...
Page 158: Stp System Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The switch with the lowest Bridge ID (switch C) was elected the root bridge, and the ports were selected to give a high port cost between switches B and C. The two (optional) Gigabit ports (default port cost = 20,000) on switch A are connected to one (optional) Gigabit port on both switch B and C.
Page 159 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Basic Settings Object Description • Protocol Version The STP protocol version setting. Valid values are:  STP (IEEE 802.1D Spanning Tree Protocol)  RSTP (IEEE 802.2w Rapid Spanning Tree Protocol) ...
Page 160: Bridge Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Port Error Recovery Control whether a port in the error-disabled state automatically will be enabled after a certain time. If recovery is not enabled, ports have to be disabled and re-enabled for normal STP operation.
Page 161: Cist Port Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Topology Flag The current state of the Topology Change Flag for this Bridge instance. • Topology Change Last The time since last Topology Change occurred. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. : Click to refresh the page immediately.
Page 162 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Controls the path cost incurred by the port. The Auto setting will set the path cost Path Cost as appropriate by the physical link speed, using the 802.1D recommended values. Using the Specific setting, a user-defined value can be entered. The path cost is used when establishing the active topology of the network.
Page 163 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. By default, the system automatically detects the speed and duplex mode used on each port, and configures the path cost according to the values shown below.
Page 164: Msti Priorities
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.7.5 MSTI Priorities This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. The MSTI Priority screen in Figure 4-7-7 appears.
Page 165: Msti Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.7.6 MSTI Configuration This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. The MSTI Configuration screen in Figure 4-7-8 appears.
Page 166: Msti Ports Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series MSTI Mapping Object Description • MSTI The bridge instance. The CIST is not available for explicit mapping, as it will receive the VLANs not explicitly mapped. • VLANs Mapped The list of VLAN's mapped to the MSTI. The VLANs must be separated with comma and/or space.
Page 167 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-7-10 : MST1 MSTI Port Configuration Page Screenshot The page includes the following fields: MSTx MSTI Port Configuration Object Description • Port The switch port number of the corresponding STP CIST (and MSTI) port. •...
Page 168: Port Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.7.8 Port Status This page displays the STP CIST port status for port physical ports in the currently selected switch. The STP Port Status screen in Figure 4-7-11 appears. Figure 4-7-11: STP Port Status Page Screenshot The page includes the following fields: Object Description...
Page 169: Port Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.7.9 Port Statistics This page displays the STP port statistics counters for port physical ports in the currently selected switch. The STP Port Statistics screen in Figure 4-7-12 appears. Figure 4-7-12: STP Statistics Page Screenshot The page includes the following fields: Object Description...
Page 170: Igmp Snooping
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8 Multicast 4.8.1 IGMP Snooping The Internet Group Management Protocol (IGMP) lets host and routers share information about multicast groups memberships. IGMP snooping is a switch feature that monitors the exchange of IGMP messages and copies them to the CPU for feature processing.
Page 171 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-8-2: Multicast Flooding Figure 4-8-3: IGMP Snooping Multicast Stream Control...
Page 172 User’s Manual of GS-5220 Ultra PoE & PoE+ Series IGMP Versions 1 and 2 Multicast groups allow members to join or leave at any time. IGMP provides the method for members and multicast routers to communicate when joining or leaving a multicast group. IGMP version 1 is defined in RFC 1112. It has a fixed packet size and no optional data.
Page 173 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The states a computer will go through to join or to leave a multicast group are shown below: Figure 4-8-4: IGMP State Transitions  IGMP Querier – A router, or multicast-enabled switch, can periodically ask their hosts if they want to receive multicast traffic. If there is more than one router/switch on the LAN performing IP multicasting, one of these devices is elected “querier”...
Page 174: Profile Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.2 Profile Table This page provides IPMC Profile related configurations. The IPMC profile is used to deploy the access control on IP multicast streams. It is allowed to create at maximum 64 Profiles with at maximum 128 corresponding rules for each. The Profile Table screen in Figure 4-8-5 appears.
Page 175: Address Entry
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to add new IPMC profile. Specify the name and configure the new entry. Click "Save”. : Click to apply changes Click to undo any changes made locally and revert to previously saved values. 4.8.3 Address Entry This page provides address range settings used in .
Page 176: Igmp Snooping Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series : Click to apply changes Click to undo any changes made locally and revert to previously saved values. Refreshes the displayed table starting from the input fields. Updates the table starting from the first entry in the IPMC Profile Address Configuration. Updates the table, starting with the entry after the last entry currently displayed.
Page 177 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Snooping Enabled Enable the Global IGMP Snooping. • Enable unregistered IPMCv4 traffic flooding. Unregistered IPMCv4 Flooding Enabled The flooding control takes effect only when IGMP Snooping is enabled. When IGMP Snooping is disabled, unregistered IPMCv4 traffic flooding is always active in spite of this setting.
Page 178: Igmp Snooping Vlan Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.5 IGMP Snooping VLAN Configuration Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found in the VLAN Table.
Page 179 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • PRI (PRI) Priority of Interface. It indicates the IGMP control frame priority level generated by the system. These values can be used to prioritize different classes of traffic. The allowed range is 0 (best effort) to 7 (highest), default interface priority value is 0 •...
Page 180: Igmp Snooping Port Group Filtering
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.6 IGMP Snooping Port Group Filtering In certain switch applications, the administrator may want to control the multicast services that are available to end users. For example, an IP/TV service based on a specific subscription plan. The IGMP filtering feature fulfills this requirement by restricting access to specified multicast services on a switch port, and IGMP throttling limits the number of simultaneous multicast groups a port can join.
Page 181: Igmp Snooping Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.7 IGMP Snooping Status This page provides IGMP Snooping status. The IGMP Snooping Status screen in Figure 4-8-10 appears. Figure 4-8-10: IGMP Snooping Status Page Screenshot The page includes the following fields: Object Description •...
Page 182: Igmp Group Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to refresh the page immediately. : Clears all Statistics counters. Auto-refresh : Automatic refresh occurs every 3 seconds. 4.8.8 IGMP Group Information Entries in the IGMP Group Table are shown on this Page. The IGMP Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the IGMP Group table, default being 20, selected through the "entries per page"...
Page 183: Igmpv3 Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.9 IGMPv3 Information Entries in the IGMP SSM Information Table are shown on this page. The IGMP SSM Information Table is sorted first by VLAN ID, then by group, and then by Port No. Diffrent source addresses belong to the same group are treated as single entry. Each page shows up to 99 entries from the IGMP SSM (Source Specific Multicast) Information table, default being 20, selected through the "entries per page"...
Page 184: Mld Snooping Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.10 MLD Snooping Configuration This page provides MLD Snooping related configuration. The MLD Snooping Configuration screen in Figure 4-8-13 appears. Figure 4-8-13: MLD Snooping Configuration Page Screenshot The page includes the following fields: Object Description •...
Page 185: Mld Snooping Vlan Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series switch that leads towards the Layer 3 multicast device or MLD querier. If an aggregation member port is selected as a router port, the whole aggregation will act as a router port. The allowed selection is Auto, Fix, Fone, default compatibility value is Auto.
Page 186 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Querier Election Enable to join MLD Querier election in the VLAN. Disable to act as a MLD Non-Querier. • Compatibility Compatibility is maintained by hosts and routers taking appropriate actions depending on the versions of MLD operating on hosts and routers within a network.
Page 187: Mld Snooping Port Group Filtering
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.12 MLD Snooping Port Group Filtering In certain switch applications, the administrator may want to control the multicast services that are available to end users. For example, an IP/TV service based on a specific subscription plan. The MLD filtering feature fulfills this requirement by restricting access to specified multicast services on a switch port, and MLD throttling limits the number of simultaneous multicast groups a port can join.
Page 188: Mld Snooping Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.13 MLD Snooping Status This page provides MLD Snooping status. The IGMP Snooping Status screen in Figure 4-8-16 appears. Figure 4-8-16: MLD Snooping Status Page Screenshot The page includes the following fields: Object Description •...
Page 189: Mld Group Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Status Indicates whether specific port is a router port or not. Buttons : Click to refresh the page immediately. : Clears all Statistics counters. Auto-refresh : Automatic refresh occurs every 3 seconds. 4.8.14 MLD Group Information Entries in the MLD Group Table are shown on this page.
Page 190: Mldv2 Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.15 MLDv2 Information Entries in the MLD SFM Information Table are shown on this page. The MLD SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by Port.
Page 191: Mvr (Multicast Vlan Registration)
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.16 MVR (Multicast VLAN Registration) The MVR feature enables multicast traffic forwarding on the Multicast VLANs. ■ In a multicast television application, a PC or a network television or a set-top box can receive the multicast stream. ■...
Page 192 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-8-19: MVR Configuration Page Screenshot The page includes the following fields: Object Description • MVR Mode Enable/Disable the Global MVR. The Unregistered Flooding control depends on the current configuration in IGMP/MLD Snooping.
Page 193 User’s Manual of GS-5220 Ultra PoE & PoE+ Series given, it should contain at least one alphabet. MVR VLAN name can be edited for the existing MVR VLAN entries or it can be added to the new entries. • IGMP Address Define the IPv4 address as source address used in IP header for IGMP control frames.
Page 194: Mvr Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The default Role is Inactive. • Immediate Leave Enable the fast leave on the port. Buttons : Click to add new MVR VLAN. Specify the VID and configure the new entry. Click "Save" : Click to apply changes : Click to undo any changes made locally and revert to previously saved values.
Page 195: Mvr Groups Information
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.8.18 MVR Groups Information Entries in the MVR Group Table are shown on this page. The MVR Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the MVR Group table, default being 20, selected through the "entries per page" input field.
Page 196 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Each page shows up to 99 entries from the MVR SFM Information Table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the MVR SFM Information Table.
Page 197: Quality Of Service
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9 Quality of Service 4.9.1 Understanding QoS Quality of Service (QoS) is an advanced traffic prioritization feature that allows you to establish control over network traffic. QoS enables you to assign various grades of network service to different types of traffic, such as multi-media, video, protocol-specific, time critical, and file-backup traffic.
Page 198: Port Policing
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.2 Port Policing This page allows you to configure the Policer settings for all switch ports. The Port Policing screen in Figure 4-9-1 appears. Figure 4-9-1: QoS Ingress Port Policers Page Screenshot The page includes the following fields: Object Description...
Page 199 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-9-2 : QoS Ingress Port Classification Page Screenshot The page includes the following fields: Object Description • Port The port number for which the configuration below applies. • CoS Controls the default class of service. All frames are classified to a CoS.
Page 200: Port Scheduler
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. 4.9.4 Port Scheduler This page provides an overview of QoS Egress Port Schedulers for all switch ports. The Port Scheduler screen in Figure 4-9-3 appears.
Page 201: Port Shaping
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.5 Port Shaping This page provides an overview of QoS Egress Port Shapers for all switch ports. The Port Shaper screen in Figure 4-9-4 appears. Figure 4-9-4: QoS Egress Port Shapers Page Screenshot The page includes the following fields: Object Description...
Page 202: Qos Egress Port Schedule And Shapers
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.5.1 QoS Egress Port Schedule and Shapers The Port Scheduler and Shapers for a specific port are configured on this page. The QoS Egress Port Schedule and Shaper screen in Figure 4-9-5 appears.
Page 203: Port Tag Remarking
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Weight This value is restricted to 1-100. This parameter is only shown if "Scheduler Mode" is set to "Weighted". The default value is "17". • Queue Scheduler Shows the weight in percent for this queue. This parameter is only shown if Percent "Scheduler Mode"...
Page 204: Qos Egress Port Tag Remarking
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Port The logical port for the settings contained in the same row. Click on the port number in order to configure tag remarking. For more detail, please refer to chapter 4.9.6.1.
Page 205: Port Dscp
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.7 Port DSCP This page allows you to configure the basic QoS Port DSCP Configuration settings for all switch ports. The Port DSCP screen in Figure 4-9-8 appears. Figure 4-9-8: QoS Port DSCP Configuration Page Screenshot The page includes the following fields: Object Description...
Page 206: Dscp-Based Qos
User’s Manual of GS-5220 Ultra PoE & PoE+ Series remarked with remapped DSCP value. The remapped DSCP value is always taken from the 'DSCP Translation->Egress Remap DP0' table.  Remap DP Aware: DSCP from analyzer is remapped and frame is remarked with remapped DSCP value.
Page 207: Dscp Translation
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • DSCP Maximum number of supported DSCP values are 64. • Trust Controls whether a specific DSCP value is trusted. Only frames with trusted DSCP values are mapped to a specific QoS class and Drop Precedence Level.
Page 208: Dscp Classification
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • DSCP Maximum number of supported DSCP values are 64 and valid DSCP value ranges from 0 to 63. • Ingress Ingress side DSCP can be first translated to new DSCP before using the DSCP for QoS class and DPL map.
Page 209: Qos Control List
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • QoS Class Available QoS Class value ranges from 0 to 7. QoS Class (0-7) can be mapped to followed parameters. • DPL Actual Drop Precedence Level.
Page 210 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The default value is 'Any'. • SMAC Displays the OUI field of Source MAC address, i.e. first three octet (byte) of MAC address. • Tag Type Indicates tag type. Possible values are: ■...
Page 211: Qos Control Entry Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.11.1 QoS Control Entry Configuration The QCE Configuration screen in Figure 4-9-13 appears. Figure 4-9-13: QCE Configuration Page Screenshot The page includes the following fields: Object Description • Port Members Check the checkbox button in case you what to make any port member of the QCL entry.
Page 212 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Frame Type Frame Type can have any of the following values Ethernet SNAP IPv4 IPv6 Note: all frame types are explained below. • Any Allow all types of frames. • EtherType Ethernet Type Valid Ethernet type can have value within 0x600-0xFFFF or 'Any' but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is 'Any'.
Page 213: Qcl Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range applicable for IP protocol UDP/TCP • Action Parameters Class QoS class: (0-7) or 'Default'. DPL Valid Drop Precedence Level can be (0-3) or 'Default'. DSCP Valid DSCP value can be (0-63, BE, CS1-CS7, EF or AF11-AF43) or 'Default'.
Page 214: Storm Control Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Ethernet: Only Ethernet frames (with Ether Type 0x600-0xFFFF) are allowed. ■ LLC: Only (LLC) frames are allowed. ■ SNAP: Only (SNAP) frames are allowed. ■ IPv4: The QCE will match only IPV4 frames. ■...
Page 215: Wred
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-9-15: Storm Control Configuration Page Screenshot The page includes the following fields: Object Description • Port The port number for which the configuration below applies. • Enable Controls whether the storm control is enabled on this switch port. •...
Page 216 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-9-16 WRED Page Screenshot The page includes the following fields: Object Description • Queue The queue number (QoS class) for which the configuration below applies. • Enable Controls whether RED is enabled for this queue. •...
Page 217 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Max. DP 1-3 is the drop probability when the average queue filling level is 100%. Frames marked with Drop Precedence Level 0 are never dropped. Min. Threshold is the average queue filling level where the queues randomly start dropping frames. The drop probability for frames marked with Drop Precedence Level n increases linearly from zero (at Min.
Page 218: Qos Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.15 QoS Statistics This page provides statistics for the different queues for all switch ports. The QoS Statistics screen in Figure 4-9-17 appears. Figure 4-9-17: Queuing Counters Page Screenshot The page includes the following fields: Object Description •...
Page 219 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-9-18: Voice VLAN Configuration Page Screenshot The page includes the following fields: Object Description • Mode Indicates the Voice VLAN mode operation. We must disable MSTP feature before we enable Voice VLAN. It can avoid the conflict of ingress filter. Possible modes are: ■...
Page 220 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Traffic Class Indicates the Voice VLAN traffic class. All traffic on Voice VLAN will apply this class. • Mode Indicates the Voice VLAN port mode. Possible port modes are: ■ Disabled: Disjoin from Voice VLAN.
Page 221: Voice Vlan Oui Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.9.17 Voice VLAN OUI Table Configure VOICE VLAN OUI table on this page. The maximum entry number is 16. Modifying the OUI table will restart auto detection of OUI process. The Voice VLAN OUI Table screen in Figure 4-9-19 appears.
Page 222: Access Control Lists
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.10 Access Control Lists ACL is an acronym for Access Control List. It is the list table of ACEs, containing access control entries that specify individual users or groups permitted or denied to specific traffic objects, such as a process or a program. Each accessible traffic object contains an identifier to its ACL.
Page 223 User’s Manual of GS-5220 Ultra PoE & PoE+ Series frames. ■ ARP: The ACE will match ARP/RARP frames. ■ IPv4: The ACE will match all IPv4 frames. ■ IPv4/ICMP: The ACE will match IPv4 frames with ICMP protocol. ■ IPv4/UDP: The ACE will match IPv4 frames with UDP protocol. ■...
Page 224: Access Control List Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.10.2 Access Control List Configuration This page shows the Access Control List (ACL), which is made up of the ACEs defined on this switch. Each row describes the ACE that is defined. The maximum number of ACEs is 512 on each switch. Click on the lowest plus sign to add a new ACE to the list.
Page 225 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Rate Limiter Indicates the rate limiter number of the ACE. The allowed range is 1 to 16. When Disabled is displayed, the rate limiter operation is disabled. • Port Redirect Indicates the port redirect operation of the ACE.
Page 226: Ace Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.10.3 ACE Configuration Configure an ACE (Access Control Entry) on this page. An ACE consists of several parameters. These parameters vary according to the frame type that you select. First select the ingress port for the ACE, and then select the frame type. Different parameter options are displayed depending on the frame type selected.
Page 227 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Ethernet Type: Only Ethernet Type frames can match this ACE. The IEEE 802.3 describes the value of Length/Type Field specifications to be greater than or equal to 1536 decimal (equal to 0600 hexadecimal). ■...
Page 228 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  MAC Parameters Object Description • SMAC Filter (Only displayed when the frame type is Ethernet Type or ARP.) Specify the source MAC filter for this ACE. ■ Any: No SMAC filter is specified. (SMAC filter status is "don't-care".) ■...
Page 229 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  ARP Parameters The ARP parameters can be configured when Frame Type "ARP" is selected. Object Description • ARP/RARP Specify the available ARP/RARP opcode (OP) flag for this ACE. ■ Any: No ARP/RARP OP flag is specified. (OP is "don't-care".) ■...
Page 230 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • RARP Target MAC Specify whether frames can hit the action according to their target hardware Match address field (THA) settings. ■ 0: RARP frames where THA is not equal to the SMAC address. ■...
Page 231 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • IP Protocol Value When "Specific" is selected for the IP protocol value, you can enter a specific value. The allowed range is 0 to 255. A frame that hits this ACE matches this IP protocol value.
Page 232 User’s Manual of GS-5220 Ultra PoE & PoE+ Series that appear. • DIP Address When "Host" or "Network" is selected for the destination IP filter, you can enter a specific DIP address in dotted decimal notation. • DIP Mask When "Network" is selected for the destination IP filter, you can enter a specific DIP mask in dotted decimal notation.
Page 233 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Hop Limit Specify the hop limit settings for this ACE. ■ zero: IPv6 frames with a hop limit field greater than zero must not be able to match this entry. ■...
Page 234 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Range: If you want to filter a specific TCP/UDP source range filter with this ACE, you can enter a specific TCP/UDP source range value. A field for entering a TCP/UDP source value appears. •...
Page 235 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • TCP PSH Specify the TCP "Push Function" (PSH) value for this ACE. ■ 0: TCP frames where the PSH field is set must not be able to match this entry. ■...
Page 236: Acl Ports Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.10.4 ACL Ports Configuration Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame matches a specific ACE. The ACL Ports Configuration screen in Figure 4-10-4 appears.
Page 237 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ■ Disabled: Port shut down is disabled. The default value is "Disabled". • State Specify the port state of this port. The allowed values are: ■ Enabled: To reopen ports by changing the volatile port configuration of the ACL user module.
Page 238: Acl Rate Limiter Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.10.5 ACL Rate Limiter Configuration Configure the rate limiter for the ACL of the switch. The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears. Figure 4-10-5: ACL Rate Limiter Configuration Page Screenshot The page includes the following fields: Object Description...
Page 239: Authentication
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11 Authentication This section is to control the access to the Managed Switch, including the user access and management control. The Authentication section contains links to the following main topics:  IEEE 802.1X Port-based Network Access Control ...
Page 240: Understanding Ieee 802.1X Port-Based Authentication
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The advantage of MAC-based authentication over 802.1X is that several clients can be connected to the same port (e.g. through a 3rd party switch or a hub) and still require individual authentication, and that the clients don't need special supplicant software to authenticate.
Page 241 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-11-1  Client—the device (workstation) that requests access to the LAN and switch services and responds to requests from the switch. The workstation must be running 802.1X-compliant client software such as that offered in the Microsoft Windows XP operating system.
Page 242 User’s Manual of GS-5220 Ultra PoE & PoE+ Series authentication server, the server's frame header is removed, leaving the EAP frame, which is then encapsulated for Ethernet and sent to the client.  Authentication Initiation and Message Exchange The switch or the client can initiate authentication. If you enable authentication on a port by using the dot1x port-control auto interface configuration command, the switch must initiate authentication when it determines that the port link state transitions from down to up.
Page 243: Authentication Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Ports in Authorized and Unauthorized States The switch port state determines whether or not the client is granted access to the network. The port starts in the unauthorized state. While in this state, the port disallows all ingress and egress traffic except for 802.1X protocol packets. When a client is successfully authenticated, the port transitions to the authorized state, allowing all traffic for the client to flow normally.
Page 244: Network Access Server Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Client The management client for which the configuration below applies. • Authentication Method Authentication Method can be set to one of the following values: ■...
Page 245 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-11-4: Network Access Server Configuration Page Screenshot The page includes the following fields: System Configuration Object Description • Mode Indicates if NAS is globally enabled or disabled on the switch. If globally disabled, all ports are allowed forwarding of frames.
Page 246 User’s Manual of GS-5220 Ultra PoE & PoE+ Series switch and the client, and therefore doesn't imply that a client is still present on a port. • Reauthentication Determines the period, in seconds, after which a connected client must be Period reauthenticated.
Page 247 User’s Manual of GS-5220 Ultra PoE & PoE+ Series In MAC-based Auth. mode, the switch will ignore new frames coming from the client during the hold time. The Hold Time can be set to a number between 10 and 1000000 seconds. •...
Page 248 User’s Manual of GS-5220 Ultra PoE & PoE+ Series this setting. The value can only be changed if the Guest VLAN option is globally enabled. Valid values are in the range [1; 255]. • Allow Guest VLAN if The switch remembers if an EAPOL frame has been received on the port for the EAPOL Seen life-time of the port.
Page 249 User’s Manual of GS-5220 Ultra PoE & PoE+ Series sent between the switch and the RADIUS server are RADIUS packets. RADIUS packets also encapsulate EAP PDUs together with other attributes like the switch's IP address, name, and the supplicant's port number on the switch. EAP is very flexible, in that it allows for different authentication methods, like MD5-Challenge, PEAP, and TLS.
Page 250 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Once a supplicant is successfully authenticated, only that supplicant will be allowed access. This is the most secure of all the supported modes. In this mode, the Port Security module is used to secure a supplicant's MAC address once successfully authenticated.
Page 251 User’s Manual of GS-5220 Ultra PoE & PoE+ Series authentication, and therefore, MAC-based Authentication has nothing to do with the 802.1X standard. The advantage of MAC-based authentication over port-based 802.1X is that several clients can be connected to the same port (e.g. through a 3rd party switch or a hub) and still require individual authentication, and that the clients don't need special supplicant software to authenticate.
Page 252 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Access-Accept packet transmitted by the RADIUS server when a supplicant is successfully authenticated. If present and valid, the port's Port VLAN ID will be changed to this VLAN ID, the port will be set to be a member of that VLAN ID, and the port will be forced into VLAN unaware mode.
Page 253 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Port-based 802.1X  Single 802.1X  Multi 802.1X For trouble-shooting VLAN assignments, use the "Monitor→VLANs→VLAN Membership and VLAN Port" pages. These pages show which modules have (temporarily) overridden the current Port VLAN configuration. Guest VLAN Operation: When a Guest VLAN enabled port's link comes up, the switch starts transmitting EAPOL Request Identity frames.
Page 254 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Restart Two buttons are available for each row. The buttons are only enabled when authentication is globally enabled and the port's Admin State is in an EAPOL-based or MAC-based mode. Clicking these buttons will not cause settings changed on the page to take effect.
Page 255: Network Access Overview
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11.4 Network Access Overview This page provides an overview of the current NAS port states for the selected switch. The Network Access Overview screen in Figure 4-11-5 appears. Figure 4-11-5: Network Access Server Switch Status Page Screenshot The page includes the following fields: Object Description...
Page 256: Network Access Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons Click to refresh the page immediately. Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. 4.11.5 Network Access Statistics This page provides detailed NAS statistics for a specific switch port running EAPOL-based IEEE 802.1X authentication. For MAC-based ports, it shows selected backend server (RADIUS Authentication Server) statistics, only.
Page 257 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Port Counters Object Description • EAPOL Counters These supplicant frame counters are available for the following administrative states: ■ Force Authorized ■ Force Unauthorized ■ Port-based 802.1X ■ Single 802.1X ■ Multi 802.1X Direction Name...
Page 258 User’s Manual of GS-5220 Ultra PoE & PoE+ Series which the Packet Body Length field is invalid. Total dot1xAuthEapolFrames The number of EAPOL frames of any type that have been transmitted by the switch. Request ID dot1xAuthEapolReqIdFr The number of EAPOL amesTx Request Identity frames that have been transmitted by...
Page 259 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Other dot1xAuthBackendOther 802.1X-based: Requests RequestsToSupplicant Counts the number of times that the switch sends an EAP Request packet following the first to the supplicant. Indicates that the backend server chose an EAP-method. MAC-based: Not applicable.
Page 260 User’s Manual of GS-5220 Ultra PoE & PoE+ Series for a given port (left-most table) or client (right-most table). Possible retransmissions are not counted. • Last Supplicant/Client Information about the last supplicant/client that attempted to authenticate. This Info information is available for the following administrative states: ■...
Page 261 User’s Manual of GS-5220 Ultra PoE & PoE+ Series no MAC address is currently selected. To populate the table, select one of the attached MAC Addresses from the table below. Attached MAC Address Object Description • Identity Shows the identity of the supplicant, as received in the Response Identity EAPOL frame. Clicking the link causes the supplicant's EAPOL and Backend Server counters to be shown in the Selected Counters table.
Page 262 User’s Manual of GS-5220 Ultra PoE & PoE+ Series : This button is available in the following modes: • Multi 802.1X • MAC-based Auth.X Click to clear both the port counters and all of the attached client's counters. The "Last Client" will not be cleared, however.
Page 263: Radius
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11.6 RADIUS This page allows you to configure the RADIUS Servers. The RADIUS Configuration screen in Figure 4-11-7 appears. Figure 4-11-7: RADIUS Server Configuration Page Screenshot The page includes the following fields: Global Configuration These setting are common for all of the RADIUS Servers.
Page 264 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Key The secret key - up to 63 characters long - shared between the RADIUS server and the switch. • NAS-IP-Address The IPv4 address to be used as attribute 4 in RADIUS Access-Request packets. If this field is left blank, the IP address of the outgoing interface is used.
Page 265: Tacacs
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11.7 TACACS+ This page allows you to configure the TACACS+ Servers. The TACACS+ Configuration screen in Figure 4-11-8 appears. Figure 4-11-8: TACACS+ Server Configuration Page Screenshot The page includes the following fields: Global Configuration These setting are common for all of the TACACS+ Servers.
Page 266: Radius Overview
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Object Description • Delete To delete a TACACS+ server entry, check this box. The entry will be deleted during the next Save. • Hostname The IP address or hostname of the TACACS+ server. •...
Page 267 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: RADIUS Authentication Server Status Overview Object Description • # The RADIUS server number. Click to navigate to detailed statistics for this server. • IP Address The IP address and UDP port number (in <IP Address>:<UDP Port>...
Page 268: Radius Details
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11.9 RADIUS Details This page provides detailed statistics for a particular RADIUS server. The RADIUS Authentication/Accounting for Server Overview screen in Figure 4-11-10 appears. Figure 4-11-10: RADIUS Authentication/Accounting for Server Overview Screenshot The page includes the following fields: RADIUS Authentication Statistics The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client MIB.
Page 269 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Access radiusAuthClientExtA The number of RADIUS Accepts ccessAccepts Access-Accept packets (valid or invalid) received from the server. Access Rejects radiusAuthClientExtA The number of RADIUS ccessRejects Access-Reject packets (valid or invalid) received from the server.
Page 270 User’s Manual of GS-5220 Ultra PoE & PoE+ Series authentication port and dropped for some other reason. Access radiusAuthClientExtA The number of RADIUS Requests ccessRequests Access-Request packets sent to the server. This does not include retransmissions. Access radiusAuthClientExtA The number of RADIUS Retransmissio ccessRetransmission Access-Request packets...
Page 271 User’s Manual of GS-5220 Ultra PoE & PoE+ Series in question. State Shows the state of the server. It takes one of the following values:  Disabled: The selected server is disabled.  Not Ready: The server is enabled, but IP communication is not yet up and running.
Page 272 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Malformed radiusAccClientExt The number of malformed Responses MalformedRespons RADIUS packets received from the server. Malformed packets include packets with an invalid length. Bad authenticators or unknown types are not included as malformed access responses.
Page 273 User’s Manual of GS-5220 Ultra PoE & PoE+ Series retransmission. Timeouts radiusAccClientExt The number of accounting Timeouts timeouts to the server. After a timeout, the client may retry to the same server, send to a different server, or give up. A retry to the same server is counted as a retransmit as well as a timeout.
Page 274: Windows Platform Radius Server Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The granularity of this measurement is 100 ms. A value of 0 ms indicates that there hasn't been round-trip communication with the server yet. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. Click to refresh the page immediately.
Page 275 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Add New RADIUS Client on the Windows 2003 server Figure 4-11-12: Windows Server – Add New RADIUS Client Setting Assign the client IP address to the Managed Switch Figure 4-11-13: Windows Server RADIUS Server Setting...
Page 276 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The shared secret key should be as same as the key configured on the Managed Switch. Figure 4-11-14: Windows Server RADIUS Server Setting Configure ports attribute of 802.1X, the same as “802.1X Port Configuration”. Figure 4-11-15: 802.1x Port Configuration Create user data.
Page 277 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-11-16: Windows 2003 AD Server Setting Path Enter ” Active Directory Users and Computers”, create legal user data; next, right-click a user what you created to enter properties, and what to be noticed:...
Page 278 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-11-17: Add User Properties Screen Figure 4-11-18: Add User Properties Screen Set the Port Authenticate Status to “Force Authorized” if the port is connected to the RADIUS server or the port is an uplink port that is connected to another switch. Or once the 802.1X starts to work, the switch might not be able to access the RADIUS server.
Page 279: X Client Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.11.11 802.1X Client Configuration Windows XP is originally 802.1X support. As to other operating systems (windows 98SE, ME, 2000), an 802.1X client utility is needed. The following procedures show how to configure 802.1X Authentication in Windows XP. Please note that if you want to change the 802.1x authentication type of a wireless client, i.e.
Page 280 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-11-20 Click “OK”. When client has associated with the Managed Switch, a user authentication notice appears in system tray. Click on the notice to continue. Figure 4-11-21: Windows Client Popup Login Request Message...
Page 281 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Enter the user name, password and the logon domain that your account belongs. 10. Click “OK” to complete the validation process. Figure 4-11-22...
Page 282: Port Limit Control
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12 Security This section is to control the access of the Managed Switch, includes the user access and management control. The Security page contains links to the following main topics:  Port Limit Control ...
Page 283 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-12-1: Port Limit Control Configuration Overview Page Screenshot The page includes the following fields: System Configuration Object Description • Mode Indicates if Limit Control is globally enabled or disabled on the switch. If globally disabled, other modules may still use the underlying functionality, but limit checks and corresponding actions are disabled.
Page 284 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Port Configuration The table has one row for each port and a number of columns, which are: Object Description • Port The port number for which the configuration below applies. • Mode Controls whether Limit Control is enabled on this port.
Page 285 User’s Manual of GS-5220 Ultra PoE & PoE+ Series point of view. The state takes one of four values:  Disabled: Limit Control is either globally disabled or disabled on the port.  Ready: The limit is not yet reached. This can be shown for all actions. ...
Page 286: Access Management
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.2 Access Management Configure access management table on this page. The maximum entry number is 16. If the application's type match any one of the access management entries, it will allow access to the switch. The Access Management Configuration screen in Figure 4-12-2 appears.
Page 287: Access Management Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.3 Access Management Statistics This page provides statistics for access management. The Access Management Statistics screen in Figure 4-12-3 appears. Figure 4-12-3: Access Management Statistics Overview Page Screenshot The page includes the following fields: Object Description •...
Page 288: Https
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.4 HTTPs Configure HTTPS on this page. The HTTPS Configuration screen in Figure 4-12-4 appears. Figure 4-12-4: HTTPS Configuration Screen Page Screenshot The page includes the following fields: Object Description • Mode Indicates the HTTPS mode operation.
Page 289: Port Security Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.5 SSH Configure SSH on this page. This page shows the Port Security status. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 290 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The status page is divided into two sections - one with a legend of user modules and one with the actual port status. The Port Security Status screen in Figure 4-12-6 appears.
Page 291 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Users Each of the user modules has a column that shows whether that module has enabled Port Security or not. A '-' means that the corresponding user module is not enabled, whereas a letter indicates that the user module abbreviated by that letter has enabled port security.
Page 292: Port Security Detail
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.7 Port Security Detail This page shows the MAC addresses secured by the Port Security module. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 293: Dhcp Snooping
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.8 DHCP Snooping DHCP Snooping is used to block intruder on the untrusted ports of DUT when it tries to intervene by injecting a bogus DHCP reply packet to a legitimate conversation between the DHCP client and server. Configure DHCP Snooping on this page.
Page 294 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-12-8: DHCP Snooping Configuration Screen Page Screenshot The page includes the following fields: Object Description • Snooping Mode Indicates the DHCP snooping mode operation. Possible modes are:  Enabled: Enable DHCP snooping mode operation. When enable DHCP snooping mode operation, the request DHCP messages will be forwarded to trusted ports and only allowed reply packets from trusted ports.
Page 295: Snooping Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.9 Snooping Table This page display the dynamic IP assigned information after DHCP Snooping mode is disabled. All DHCP clients obtained the dynamic IP address from the DHCP server will be listed in this table except for local VLAN interface IP addresses.
Page 296 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-12-10: IP Source Guard Configuration Screen Page Screenshot The page includes the following fields: Object Description • Mode of IP Source Enable the Global IP Source Guard or disable the Global IP Source Guard. All Guard Configuration configured ACEs will be lost when the mode is enabled.
Page 297: Ip Source Guard Static Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.11 IP Source Guard Static Table This page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11 appears. Figure 4-12-11: Static IP Source Guard Table Screen Page Screenshot The page includes the following fields: Object Description...
Page 298: Arp Inspection
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.12.12 ARP Inspection ARP Inspection is a secure feature. Several types of attacks can be launched against a host or devices connected to Layer 2 networks by "poisoning" the ARP caches. This feature is used to block such attacks. Only valid ARP requests and responses can go through DUT.
Page 299: Arp Inspection Static Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series of "Check VLAN". The default setting of "Check VLAN" is disabled. When the setting of "Check VLAN" is disabled, the log type of ARP Inspection will refer to the port setting. And the setting of "Check VLAN" is enabled, the log type of ARP Inspection will refer to the VLAN setting.
Page 300: Dynamic Arp Inspection Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Delete Check to delete the entry. It will be deleted during the next save. • Port The logical port for the settings. • VLAN ID The VLAN ID for the settings. •...
Page 301 User’s Manual of GS-5220 Ultra PoE & PoE+ Series...
Page 302 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The “>>” will use the last entry of the currently displayed as a basis for the next lookup. When the end is reached the text "No more entries" is shown in the displayed table. Use the “|<<” button to start over. The page includes the following fields: Object Description •...
Page 303: Address Table
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.13 Address Table Switching of frames is based upon the DMAC address contained in the frame. The Managed Switch builds up a table that maps MAC addresses to switch ports for knowing which ports the frames should go to (based upon the DMAC address in the frame ). This table contains both static and dynamic entries.
Page 304 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Disable Automatic Enables/disables the automatic aging of dynamic entries Aging • Aging Time The time after which a learned entry is discarded. By default, dynamic entries are removed from the MAC after 300 seconds. This removal is also called aging. (Range: 10-10000000 seconds;...
Page 305: Mac Address Table Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.13.2 MAC Address Table Status Dynamic MAC Table Entries in the MAC Table are shown on this page. The MAC Table contains up to 8192 entries, and is sorted first by VLAN ID, then by MAC address.
Page 306 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Type Indicates whether the entry is a static or dynamic entry. • The VLAN ID of the entry. VLAN • MAC Address The MAC address of the entry.
Page 307: Link Layer Discovery Protocol
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.14 LLDP 4.14.1 Link Layer Discovery Protocol Link Layer Discovery Protocol (LLDP) is used to discover basic information about neighboring devices on the local broadcast domain. LLDP is a Layer 2 protocol that uses periodic broadcasts to advertise information about the sending device. Advertised information is represented in Type Length Value (TLV) format according to the IEEE 802.1ab standard, and can include details such as device identification, capabilities and configuration settings.
Page 308 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: LLDP Parameters Object Description • Tx Interval The switch is periodically transmitting LLDP frames to its neighbors for having the network discovery information up-to-date. The interval between each LLDP frame is determined by the Tx Interval value.
Page 309 User’s Manual of GS-5220 Ultra PoE & PoE+ Series  Tx only The switch will drop LLDP information received from neighbors, but will send out LLDP information.  Disabled The switch will not send out LLDP information, and will drop LLDP information received from neighbors.
Page 310: Lldp Med Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to apply changes Click to undo any changes made locally and revert to previously saved values. 4.14.3 LLDP MED Configuration This page allows you to configure the LLDP-MED. The LLDPMED Configuration screen in Figure 4-14-2 appears.
Page 311 User’s Manual of GS-5220 Ultra PoE & PoE+ Series come with inappropriate knowledge of the network policy. With this in mind LLDP-MED defines an LLDP-MED Fast Start interaction between the protocol and the application layers on top of the protocol, in order to achieve these related properties.
Page 312 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Floors: Representing altitude in a form more relevant in buildings which have different floor-to-floor dimensions. An altitude = 0.0 is meaningful even outside a building, and represents ground level at the given latitude and longitude. Inside a building, 0.0 represents the floor level associated with ground level at the main entrance.
Page 313 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Zip code Postal/zip code - Example: 2791 • Building Building (structure) - Example: Low Library • Apartment Unit (Apartment, suite) - Example: Apt 42 • Floor Floor - Example: 4 •...
Page 314 User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4. Video Conferencing 5. Streaming Video 6. Control / Signaling (conditionally support a separate network policy for the media types above) A large network may support multiple VoIP policies across the entire organization, and different policies per application type. LLDP-MED allows multiple policies to be advertised per port, each corresponding to a different application type.
Page 315 User’s Manual of GS-5220 Ultra PoE & PoE+ Series VLAN (see Tagged flag below), then the L2 priority field is ignored and only the DSCP value has relevance.  Video Conferencing - for use by dedicated Video Conferencing equipment and other similar appliances supporting real-time interactive video/audio services.
Page 316: Lldp-Med Neighbor
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Port Policies Configuration Every port may advertise a unique set of network policies or different attributes for the same network policies, based on the authenticated user identity or port configuration. Object Description •...
Page 317 User’s Manual of GS-5220 Ultra PoE & PoE+ Series LLDP-MED Network Connectivity Devices, as defined in TIA-1057, provide access to the IEEE 802 based LAN infrastructure for LLDP-MED Endpoint Devices. An LLDP-MED Network Connectivity Device is a LAN access device based on any of the following technologies: 1.
Page 318 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The LLDP-MED Communication Endpoint (Class III) definition is applicable to all endpoint products that act as end user communication appliances supporting IP media. Capabilities include all of the capabilities defined for the previous Generic Endpoint (Class I) and Media Endpoint (Class II) classes, and are extended to include aspects related to end user devices.
Page 319 User’s Manual of GS-5220 Ultra PoE & PoE+ Series distribution and other similar applications supporting streaming video services that require specific network policy treatment. Video applications relying on TCP with buffering would not be an intended use of this application type. ...
Page 320: Neighbor
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.14.5 Neighbor This page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected. The LLDP Neighbor Information screen in Figure 4-14-4 appears.
Page 321: Port Statistics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.14.6 Port Statistics This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to the whole switch, while local counters refers to counters for the currently selected switch. The LLDP Statistics screen in Figure 4-14-5 appears.
Page 322 User’s Manual of GS-5220 Ultra PoE & PoE+ Series LLDP Statistics Local Counters The displayed table contains a row for each port. The columns hold the following information: Object Description • Local Port The port on which LLDP frames are received or transmitted. •...
Page 323: Network Diagnostics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.15 Network Diagnostics This section provide the Physical layer and IP layer network diagnostics tools for troubleshoot. The diagnostic tools are designed for network manager to help them quickly diagnose problems between point to point and better service customers. Use the Diagnostics menu items to display and configure basic administrative details of the Managed Switch.
Page 324: Ping
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.15.1 Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press “Start”, 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply.
Page 325: Ipv6 Ping
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.15.2 IPv6 Ping This page allows you to issue ICMPv6 PING packets to troubleshoot IPv6 connectivity issues. After you press “Start”, 5 ICMPv6 packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply.
Page 326: Remote Ip Ping Test
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.15.3 Remote IP Ping Test This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues on special port. After you press “Test”, 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply.
Page 327: Cable Diagnostics
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.15.4 Cable Diagnostics This page is used for running the Cable Diagnostics. Press to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds.
Page 328 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Cable Status Port: Port number. Pair: The status of the cable pair. OK - Correctly terminated pair Open - Open pair Short - Shorted pair Short A - Cross-pair short to pair A Short B - Cross-pair short to pair B Short C - Cross-pair short to pair C Short D - Cross-pair short to pair D...
Page 329: Power Over Ethernet
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.16 Power over Ethernet Providing up to 16/24 PoE, in-line power interfaces, the GS-5220 Ultra PoE & PoE+ Series Switch can easily build a power that centrally controls IP phone system, IP Camera system, AP group for the enterprise. For instance, 16/24 cameras / APs can be easily installed around the corners of the company for surveillance demands or a wireless roaming environment in the office can be built.
Page 330 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Wireless LAN Access Points Access points can be installed at museums, sightseeing sites, airports, hotels, campuses, factories, warehouses, etc. 6~12 watts IP Surveillance IP cameras can be installed at enterprises, museums, campuses, hospitals, banks, etc.
Page 331: System Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.16.2 System Configuration In a power over Ethernet system, operating power is applied from a power source (PSU or power supply unit) over the LAN infrastructure to powered devices (PDs), which are connected to ports. Under some conditions, the total output power required by PDs can exceed the maximum available power provided by the PSU.
Page 332: Power Over Ethernet Configuration
Allocation-Consumption mode: System offers PoE power according to PD real power consumption. • Power Supply Budget Set limit value of the total PoE port providing power to the PDs. GS-5220-24P4X and GS-5220-24P4XR GS-5220-16UP4S2X and GS-5220-16UP4S2XR GS-5220-24UP4X and GS-5220-24UP4XR available maximum value is 400 watts.
Page 333: Port Sequential
User’s Manual of GS-5220 Ultra PoE & PoE+ Series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. PD Classifications A PD may be classified by the PSE based on the classification information provided by the PD. The intent of PD classification is to provide information about the maximum power required by the PD during operation.
Page 334: Port Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Sequential Power up Allows user to enable or disable Sequential Power up function. Option • Sequential Power up Allows user to configure the PoE Port Start Up interval time. Interval •...
Page 335 It can limit the port PoE supply wattage. Per port maximum value must be less than 72 watts(GS-5220-16UP4S2X/R, GS-5220-24UP4X/R and GS-5220-24UPL4X/R) and 36 watts(GS-5220-24P4X/R and GS-5220-24PL4X/R); total ports values must be less than the Power Reservation value. Once power overload is detected, the port will automatically shut down and continue to be in detection mode until Pad’s power consumption...
Page 336: Poe Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.16.6 PoE Status This page allows the user to inspect the total power consumption, total power reserved and current status for all PoE ports. The screen in Figure 4-16-5 appears. Figure 4-16-5:PoE Status Screenshot The page includes the following fields: Object Description...
Page 337: Poe Schedule
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Reserved Power Shows how much the total power is reserved for all PDs. (Reserved mode) • PoE Temperature Displays the current operating temperature of the first PoE chip unit. • Current Power Shows the total watts usage of Managed PoE Switch.
Page 338 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Scheduled Power Recycling The Managed PoE switch allows each of the connected PoE IP cameras to reboot in a specific time each week. Therefore, it will reduce the chance of IP camera crash resulting from buffer overflow. The screen in Figure 4-16-6 appears.
Page 339 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-16-6: PoE Schedule Screenshot Please press Add New Rule button to start settingPoE Schedule function. You have to set PoE schedule via profile and then go back to PoE Port Configuration, and select “Schedule” mode from per port “PoE Mode” option and then you can indicate which schedule profile could be apply to the PoE port.
Page 340 User’s Manual of GS-5220 Ultra PoE & PoE+ Series administrator has this kind of requirement. • Reboot Only Allows user to reboot PoE function by PoE reboot schedule. Please note that if administrator enables this function, PoE schedule will not set time to profile. This function is only for PoE port reset at the indicated time.
Page 341: Lldp Poe Neighbours
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.16.8 LLDP PoE Neighbours This page provides a status overview for all LLDP PoE neighbors. The displayed table contains a row for each port on which an LLDP PoE neighbor is detected. The columns hold the following information: The screen in Figure 4-16-7 appears.
Page 342: Loop Protection
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.17 Loop Protection This chapter describes enabling loop protection function that provides loop protection to prevent broadcast loops in Managed Switch. 4.17.1 Configuration This page allows the user to inspect the current Loop Protection configurations, and possibly change them as well as screen in Figure 4-17-1 appears.
Page 343: Loop Protection Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Transmission Time The interval between each loop protection PDU sent on each port. Valid values are 1 to 10 seconds. • Shutdown Time The period (in seconds) for which a port will be kept disabled in the event of a loop is detected (and the port action shuts down the port).
Page 344 User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Port The Managed Switch port number of the logical port. • Action The currently configured port action. • Transmit The currently configured port transmit mode. •...
Page 345: Rmon Alarm Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18 RMON RMON is the most important expansion of the standard SNMP. RMON is a set of MIB definitions, used to define standard network monitor functions and interfaces, enabling the communication between SNMP management terminals and remote monitors.
Page 346 User’s Manual of GS-5220 Ultra PoE & PoE+ Series protocol.  InNUcastPkts: The number of broadcast and multi-cast packets delivered to a higher-layer protocol.  InDiscards: The number of inbound packets that are discarded even the packets are normal.  InErrors: The number of inbound packets that contains errors preventing them from being deliverable to a higher-layer protocol.
Page 347: Rmon Alarm Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18.2 RMON Alarm Status This page provides an overview of RMON Alarm entries. Each page shows up to 99 entries from the Alarm table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Alarm table.
Page 348: Rmon Event Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18.3 RMON Event Configuration Configure RMON Event table on this page. The entry index key is ID; screen in Figure 4-18-3 appears. Figure 4-18-4: RMON Event Configuration Page Screenshot The page includes the following fields: Object Description •...
Page 349: Rmon Event Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18.4 RMON Event Status This page provides an overview of RMON Event table entries. Each page shows up to 99 entries from the Event table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Event table.
Page 350: Rmon History Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18.5 RMON History Configuration Configure RMON History table on this page. The entry index key is ID; screen in Figure 4-18-6 appears. Figure 4-18-6: RMON History Configuration Page Screenshot The page includes the following fields: Object Description •...
Page 351: Rmon History Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18.6 RMON History Status This page provides an detail of RMON history entries; screen in Figure 4-18-7 appears. Figure 4-18-7: RMON History Overview Page Screenshot The page includes the following fields: Object Description •...
Page 352: Rmon Statistics Configuration
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Utilization The best estimate of the mean physical layer network utilization on this interface during this sampling interval, in hundredths of a percent. Buttons : Click to refresh the page immediately. Auto-refresh Check this box to refresh the page automatically.
Page 353: Rmon Statistics Status
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.18.8 RMON Statistics Status This page provides an overview of RMON Statistics entries. Each page shows up to 99 entries from the Statistics table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Statistics table.
Page 354 User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Coll. The best estimate of the total number of collisions in this Ethernet segment. • 64 Bytes The total number of packets (including bad packets) received that were 64 octets in length.
Page 355: Onvif
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.19 ONVIF ONVIF (Open Network Video Interface Forum) is a global and open industry forum with the goal of facilitating the development and use of a global open standard for the interface of physical IP-based security products – or, in other words, to create a standard for how IP products within video surveillance and other physical security areas can communicate with each other.
Page 356: Onvif Device List
User’s Manual of GS-5220 Ultra PoE & PoE+ Series • Manufacturer The ONVIF Device’s Manufacturer of the entry. • Model The ONVIF Device’s Model Name of the entry. • IP Address The ONVIF Device’s IP Address of the entry. • MAC Address The ONVIF Device’s MAC address of the entry.
Page 357: Map Upload / Edit
User’s Manual of GS-5220 Ultra PoE & PoE+ Series The page includes the following fields: Object Description • Login(Optional) Allows for filling one set of User name and Password. • Port This is the logical port number for this row. •...
Page 358 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Figure 4-19-3: Map Upload / Edit Page Screenshot The page includes the following fields: Object Description • MAP Select Allows to select Map1/2/3 for uploading Map. • Description Indicates the map’s description. •...
Page 359: Floor Map
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 4.19.4 Floor Map This page allows the clients for planning the ONVIF devices with the uploaded e-Map. It can select the ONVIF devices from Device List and it also can modify the e-Map’s Zoom and Scale; screen in Figure 4-19-3 appears.
Page 360: Switch Operation
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 5. SWITCH OPERATION 5.1 Address Table The Managed Switch is implemented with an address table. This address table is composed of many entries. Each entry is used to store the address information of some nodes in the network, including MAC address, port no, etc. This information comes from the learning process of Managed Switch.
Page 361: Auto-Negotiation
User’s Manual of GS-5220 Ultra PoE & PoE+ Series 5.5 Auto-Negotiation The STP ports on the Switch have built-in "Auto-negotiation". This technology automatically sets the best possible bandwidth when a connection is established with another network device (usually at Power On or Reset). This is done by detecting the modes and speeds both connected devices are capable of.
Page 362: Troubleshooting
User’s Manual of WGSW-48040HP 6. TROUBLESHOOTING This chapter contains information to help you solve issues. If the Managed Switch is not functioning properly, make sure the Managed Switch was set up according to instructions in this manual. ■ The Link LED is not lit. Solution: Check the cable connection and remove duplex mode of the Managed Switch.
Page 363: Appendix A: Networking Connection
User’s Manual of WGSW-48040HP APPENDIX A: Networking Connection A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T PIN NO MDI-X BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- Implicit implementation of the crossover function within a twisted-pair cable, or at a wiring panel, while not expressly forbidden, is beyond the scope of this standard.
Page 364 User’s Manual of WGSW-48040HP The standard cable, RJ45 pin assignment The standard RJ45 receptacle/connector There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight-through cable and crossover cable connection: Straight Cable SIDE 1 SIDE 2...
Page 365: Appendix B : Glossary
User’s Manual of GS-5220 Ultra PoE & PoE+ Series APPENDIX B : GLOSSARY ACE is an acronym for Access Control Entry. It describes access permission associated with a particular ACE ID. There are three ACE frame types (Ethernet Type, ARP, and IPv4) and two ACE actions (permit and deny). The ACE also contains many detailed, different parameter options that are available for individual application.
Page 366 User’s Manual of GS-5220 Ultra PoE & PoE+ Series ACL|Rate Limiters: On this page, you can configure the rate limiters. There can be 15 different rate limiters, each ranging from 1 to 1024K packets per second. Under "Ports" and "Access Control List", you can assign a Rate Limiter ID to the ACE(s) or ingress port(s).
Page 367 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Auto-Negotiation Auto-negotiation is the process where two different devices establish the mode of operation and the speed settings that can be shared by those devices for a link. CC is an acronym for Continuity Check. It is a MEP functionality that is able to detect loss of continuity in a network by transmitting CCM frames to a peer MEP.
Page 368 User’s Manual of GS-5220 Ultra PoE & PoE+ Series DHCP used by networked computers (clients) to obtain IP addresses and other parameters such as the default gateway, subnet mask, and IP addresses of DNS servers from a DHCP server. The DHCP server ensures that all IP addresses are unique, for example, no IP address is assigned to a second client while the first client's assignment is valid (its lease has not expired).
Page 369 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Dotted Decimal Notation Dotted Decimal Notation refers to a method of writing IP addresses using decimal numbers and dots as separators between octets. An IPv4 dotted decimal address has the form x.y.z.w, where x, y, z, and w are decimal numbers between 0 and 255. DSCP DSCP is an acronym for Differentiated Services Code Point.
Page 370 User’s Manual of GS-5220 Ultra PoE & PoE+ Series command to the Web server directing it to fetch and transmit the requested web page. The other main standard that controls how the World Wide Web works is HTML, which covers how web pages are formatted and displayed. Any Web server machine contains, in addition to the web page files it can serve, an HTTP daemon, a program that is designed to wait for HTTP requests and handle them when they arrive.
Page 371 User’s Manual of GS-5220 Ultra PoE & PoE+ Series IGMP Querier A router sends IGMP Query messages onto a particular link. This router is called the Querier. IMAP IMAP is an acronym for Internet Message Access Protocol. It is a protocol for email clients to retrieve email messages from a mail server.
Page 372 User’s Manual of GS-5220 Ultra PoE & PoE+ Series LACP LACP is an IEEE 802.3ad standard protocol. The Link Aggregation Control Protocol allows bundling several physical ports together to form a single logical port. LLDP LLDP is an IEEE 802.1ab standard protocol. The Link Layer Discovery Protocol(LLDP) specified in this standard allows stations attached to an IEEE 802 LAN to advertise, to other stations attached to the same IEEE 802 LAN, the major capabilities provided by the system incorporating that station, the management address or addresses of the entity or entities that provide management of...
Page 373 User’s Manual of GS-5220 Ultra PoE & PoE+ Series MD5 is an acronym for Message-Digest algorithm 5. MD5 is a message digest algorithm, used cryptographic hash function with a 128-bit hash value. It was designed by Ron Rivest in 1991. MD5 is officially defined in RFC 1321 - The MD5 Message-Digest Algorithm.
Page 374 User’s Manual of GS-5220 Ultra PoE & PoE+ Series NFS is an acronym for Network File System. It allows hosts to mount partitions on a remote system and use them as though they are local file systems. NFS allows the system administrator to store resources in a central location on the network, providing authorized users continuous access to them, which means NFS supports sharing of files, printers, and other resources as persistent storage over a computer network.
Page 375 User’s Manual of GS-5220 Ultra PoE & PoE+ Series PD is an acronym for Powered Device. In a PoE> system the power is delivered from a PSE (power sourcing equipment) to a remote device. The remote device is called a PD. PHY is an abbreviation for Physical Interface Transceiver and is the device that implement the Ethernet physical layer (IEEE-802.3).
Page 376 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Private VLAN In a private VLAN, communication between ports in that private VLAN is not permitted. A VLAN can be configured as a private VLAN. PTP is an acronym for Precision Time Protocol, a network protocol for synchronizing the clocks of computer systems. QCE is an acronym for QoS Control Entry.
Page 377 User’s Manual of GS-5220 Ultra PoE & PoE+ Series class. There is a one to one mapping between QoS class, queue and priority. A QoS class of 0 (zero) has the lowest priority. RARP RARP is an acronym for Reverse Address Resolution Protocol. It is a protocol that is used to obtain an IP address for a given hardware address, such as an Ethernet address.
Page 378 User’s Manual of GS-5220 Ultra PoE & PoE+ Series SHA is an acronym for Secure Hash Algorithm. It designed by the National Security Agency (NSA) and published by the NIST as a U.S. Federal Information Processing Standard. Hash algorithms compute a fixed-length digital representation (known as a message digest) of an input data sequence (the message) of any length.
Page 379 User’s Manual of GS-5220 Ultra PoE & PoE+ Series SSH is an acronym for Secure SHell. It is a network protocol that allows data to be exchanged using a secure channel between two networked devices. The encryption used by SSH provides confidentiality and integrity of data over an insecure network.
Page 380 User’s Manual of GS-5220 Ultra PoE & PoE+ Series Common network applications that use TCP include the World Wide Web (WWW), e-mail, and File Transfer Protocol (FTP). TELNET TELNET is an acronym for Teletype Network. It is a terminal emulation protocol that uses the Transmission Control Protocol (TCP) and provides a virtual connection between TELNET server and TELNET client.
Page 381 User’s Manual of GS-5220 Ultra PoE & PoE+ Series UDP provides two services not provided by the IP layer. It provides port numbers to help distinguish different user requests and, optionally, a checksum capability to verify that the data arrived intact. Common network applications that use UDP include the Domain Name System (DNS), streaming media applications such as IPTV, Voice over IP (VoIP), and Trivial File Transfer Protocol (TFTP).
Page 382 User’s Manual of GS-5220 Ultra PoE & PoE+ Series WEP is an acronym for Wired Equivalent Privacy. WEP is a deprecated algorithm to secure IEEE 802.11 wireless networks. Wireless networks broadcast messages using radio, so are more susceptible to eavesdropping than wired networks.
Page 383 User’s Manual of GS-5220 Ultra PoE & PoE+ Series WRED WRED is an acronym for Weighted Random Early Detection. It is an active queue management mechanism that provides preferential treatment of higher priority frames when traffic builds up within a queue. A frame's DP level is used as input to WRED.

This manual is also suitable for:

Gs-5220-16up4s2xr Gs-5220-24pl4xr Gs-5220-24up4x Gs-5220-24up4xr Gs-5220-24p4xr Gs-5220-16up4s2x ... Show all

Planet Networking & Communication GS-5220-24P4X User Manual

Quick Links

Related Manuals for Planet Networking & Communication GS-5220-24P4X

Summary of Contents for Planet Networking & Communication GS-5220-24P4X
