PD @ 30.8
watts
Power Requirements
Power Consumption (Full
Loading)
ESD Protection
Dimensions (W x D x H)
Enclosure
Fan
Weight
Layer 2 Function
Port Configuration
Port Status
Port Mirroring
VLAN
Link Aggregation
QoS
IGMP Snooping
MLD Snooping
Access Control List
12 units
100~240V AC, 50/60Hz, 7A
AC 110V:
Max. 26.7 watts/91.6BTU (Power on without any connection)
Max. 447 watts/1533.6BTU (Full loading with PoE function)
AC 220V:
Max. 27.7 watts/95.03BTU (Power on without any connection)
Max. 452 watts/1550.8BTU (Full loading with PoE function)
6KV DC
440 x 300 x 44.5 mm, 1U height
Metal
3 x smart fan
4546g (GS-5220-24P4X)
Port disable/enable
Auto-negotiation 10/100/1000Mbps full or half duplex mode selection
Flow control disable/enable
Display each port's speed duplex mode, link status, flow control status, auto-negotiation
status, trunk status
TX/RX/Both
Many-to-1 monitor
802.1Q tagged-based VLAN, up to 256 VLAN groups
Q-in-Q tunneling
Private VLAN edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
IP Subnet-based VLAN
MVR (Multicast VLAN registration)
Up to 256 VLAN groups, out of 4094 VLAN IDs
IEEE 802.3ad LACP/static trunk
10 groups of 16-port trunk supported
Traffic classification based, strict priority and WRR
8-level priority for switching
- Port number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP field in IP packet
IGMP (v1/v2/v3) snooping, up to 255 multicast groups
IGMP querier mode support
MLD (v1/v2) snooping, up to 255 multicast groups
MLD querier mode support
IP-based ACL / MAC-based ACL
Up to 256 entries
User's Manual of GS-5220 Ultra PoE & PoE+ Series
100-240V AC, 50/60Hz, 7A
48V DC @ 2A, Range: 36 ~ 60V
4570g (GS-5220-24P4XR)
