Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
: Clears the counters for the selected server. The "Pending Requests" counter will not be cleared by this
operation.

4.11.10 Windows Platform RADIUS Server Configuration

Setup the RADIUS server and assign the client IP address to the Managed switch. In this case, field in the default IP Address
of the Managed Switch with 192.168.0.100. And also make sure the shared secret key is as same as the one you had set at
the Managed Switch's 802.1x system configuration – 12345678 at this case.
1. Configure the IP Address of remote RADIUS server and secret key.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-11-11: RADIUS Server Configuration Screenshot
274
The granularity of this measurement is
100 ms. A value of 0 ms indicates that
there hasn't been round-trip
communication with the server yet.
