Now, you can use the Web management interface to continue the switch management or manage the Managed Switch by Web
interface. The Switch Menu on the left of the web page lets you access all the commands and statistics the Managed Switch
provides.
1. It is recommended to use Internet Explore 7.0 or above to access Managed Switch.
2. The changed IP address takes effect immediately after clicking on the Save button. You need to
use the new IP address to access the Web interface.
3. For security reason, please change and memorize the new password after this first setup.
4. Only accept command in lowercase letter under web interface.

4.1 Main Web Page

The Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you to
access the Managed Switch using the Web browser of your choice. This chapter describes how to use the Managed Switch's
Web browser interface to configure and manage it.
Main Functions Menu
Help Button
Panel Display
The web agent displays an image of the Managed Switch's ports. The Mode can be set to display different information for the
ports, including Link up or Link down. Clicking on the image of a port opens the Port Statistics page.
The port status are illustrated as follows:
Copper Port Link Status
Figure 4-1-4: Web Main Page
State Disabled
RJ45 Ports
SFP Ports
User's Manual of GS-5220 Ultra PoE & PoE+ Series
SFP/SFP+ Port Link
Down Link
67
Main Screen
