Environment
Operating
Storage
GS-5220-16UP4S2X and GS-5220-16UP4S2XR
Product
Hardware Specifications
Copper Ports
SFP/mini-GBIC Slots
SFP+ Slots
Console
Switch Architecture
Switch Fabric
Throughput
Address Table
Shared Data Buffer
Flow Control
Jumbo Frame
Reset Button
Dimensions (W x D x H)
Weight
LED
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP v3
RFC 2710 MLD v1
FRC 3810 MLD v2
Temperature: 0 ~ 50 degrees C for AC power input
Relative Humidity: 5 ~ 95% (non-condensing)
Temperature: -40 ~ 80 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
GS-5220-16UP4S2X and GS-5220-16UP4S2XR
16 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
4 100/1000BASE-X SFP interfaces,
Compatible with 100BASE-FX SFP transceiver
2 10GbBASE-SR/LR SFP+ interfaces (Port-21 to Port-22)
Compatible with 1000BASE-SX/LX/BX SFP transceiver
1 x RS232-to-RJ45 serial port (115200, 8, N, 1)
Store-and-Forward
80Gbps/non-blocking
59.52Mpps@64Bytes
16K entries, automatic source address learning and aging
32M bits
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
10K bytes
< 5 sec: System reboot
> 5 sec: Factory default
440 x 300 x 44.5 mm, 1U height
4466g (GS-5220-16UP4S2X)
4503g (GS-5220-16UP4S2XR)
System:
SYS (Green)
AC/PWR (Green)
DC (Green) (GS-5220-16UP4S2XR Only)
Fan1/2/3 Alert (Red)
PoE PWR Alert (Red)
PoE Ethernet Interfaces (Port 1 to Port 16):
PoE-in-Use (bt-Green) (af/at- Orange)
Ethernet Interfaces (Port 1 to Port 16):
1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange)
100/1000Mbps SFP Interfaces (Port 17 to Port 20):
1000 (Green), 100 (Orange)
1/10G SFP+ Interfaces (Port 21 to Port 22):
User's Manual of GS-5220 Ultra PoE & PoE+ Series
29
