1.2 Product Description

Amazing Ultra PoE Managed Switch with Advanced L2+/L4 Switching and Security
PLANET GS-5220 Ultra PoE & PoE+ Series is a Cost-optimized, 1U, Gigabit Ultra PoE Managed Switch featuring PLANET
intelligent PoE functions to improve the availability of critical business applications.
management and built-in L2+/L4 Gigabit switching engine along with 16/24 10/100/1000BASE-T ports featuring 36/75-watt
PoE, 4 Gigabit TP/SFP combo ports and 2/4 additional 10Gigabit SFP+ ports. With a total power budget of up to 400/600
watts for different kinds of PoE applications, the
ultra PoE network solution for small businesses and enterprises.
Convenient and Smart ONVIF Devices with Detection Feature
PLANET has newly developed an awesome feature -- ONVIF Support -- which is specifically designed for co-operating with
Video IP surveillances. From the GS-5220 Ultra PoE & PoE+ Series GUI, clients just need one click to search and show all of
the ONVIF devices via network application. In addition, clients can upload floor images into switch and allows for deploying
location of surveillance devices for easier inspection and planning. Moreover, clients can get real-time surveillance's information
and online/offline status, and it also allows PoE reboot control from GUI.
75 Watts of Power over 4-pair UTP (For Ultra PoE Switches)
The GS-5220 Ultra PoE Series' ultra PoE solution adopts the IEEE 802.3at/af standard. Instead of delivering power over 2-pair
twisted UTP – be it end-span (Pins 1,2,3 and 6) or mid-span (Pins 4,5,7 and 8), it provides the capability to source up to 75 watts
of power by using all the four pairs of standard Cat.5e/6 Ethernet cabling. In the new 4-pair system, two PSE controllers will be
used to power both the data pairs and the spare pairs. It can offer more PoE applications, such as:
■ PoE PTZ speed dome
■ Any network device that needs higher PoE power to work normally
■ Thin-client
■ AIO (All-in-One) touch PC
■ Remote digital signage display
User's Manual of GS-5220 Ultra PoE & PoE+ Series
GS-5220 Ultra PoE & PoE+ Series
12
It provides IPv6/IPv4 dual stack
provides a quick, safe and cost-effective
