The page includes the following fields:
Object
• Port to mirror on
•
Port
•
Mode
For a given port, a frame is only transmitted once. It is therefore not possible to mirror Tx frames on
the mirror port. Because of this, mode for the selected mirror port is limited to Disabled or Rx only.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Description
Frames from ports that have either source (rx) or destination (tx) mirroring enabled are
mirrored to this port. Disabled disables mirroring.
The logical port for the settings contained in the same row.
Select mirror mode.
■
Rx only: Frames received at this port are mirrored to the mirroring port. Frames
transmitted are not mirrored.
■
Tx only: Frames transmitted from this port are mirrored to the mirroring port. Frames
received are not mirrored.
■
Disabled: Neither frames transmitted or frames received are mirrored.
■
Both: Frames received and frames transmitted are mirrored to the mirror port.
