1.5 Product Specifications

GS-5220-24P4X and GS-5220-24P4XR
Product
Hardware Specifications
Copper Ports
SFP/mini-GBIC Slots
10Gbps Fiber Uplink Ports
Console
Switch Architecture
Switch Fabric
Throughput
Address Table
Shared Data Buffer
Flow Control
Jumbo Frame
Reset Button
LED
Power over Ethernet
PoE Standard
PoE Power Supply Type
PoE Port Power Output
Ability
Power Pin Assignment
PoE Power Budget
PD @ 7 watts
PoE Ability
PD @ 15.4
watts
GS-5220-24P4X
24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports with IEEE 802.3at PoE injector
4 100/1000BASE-X SFP combo interfaces with Port-21 to Port-24
Supports 100/1000Mbps dual mode and DDM
4 1/10GBASE-SR/LR SFP+ slots
Supports 1/10Gbps dual mode and DDM
1 RJ45 serial port (115200, 8, N, 1)
Store-and-Forward
128Gbps/non-blocking
95 Mpps@64 bytes
16K entries, automatic source address learning and aging
32M bytes
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
10K bytes
< 5 sec: System reboot
> 5 sec: Factory default
System:
SYS (Green)
PWR (Green) (GS-5220-24P4XR showed AC)
DC (Green) (GS-5220-24P4XR Only)
FAN1 (Red), FAN2 (Red), FAN3 (Red), PoE PWR (Red)
Ethernet Interfaces (Port 1 to Port 24):
1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange)
PoE Ethernet Interfaces (Port 1 to Port 24):
PoE-in-Use (af/at-Orange)
100/1000Mbps SFP Combo Interfaces (Port-21 to Port-24):
1000 (Green), 100 (Orange)
1/10G SFP+ Interfaces (Port-25 to Port-28):
1000 (Green), 10G (Orange)
IEEE 802.3at PoE Plus PSE
End-span
Max. 36 watts
1/2(-), 3/6(+)
400 watts max.
24 units
24 units
User's Manual of GS-5220 Ultra PoE & PoE+ Series
GS-5220-24P4XR
23
