Planet Networking & Communication GS-5220-24P4X User Manual page 30

Power Consumption
Power Requirements – AC
Power Requirements – DC
ESD Protection
Fan
Power over Ethernet
PoE Standard
PoE Power Supply Type
PoE Power Output
Power Pin Assignment
PoE Power Budget
PoE Ability PD @ 15 watts
PoE Ability PD @ 30 watts
PoE Ability PD @ 60 watts
Layer 2 Management Functions
Port Configuration
Port Status
Port Mirroring
VLAN
Link Aggregation
Spanning Tree Protocol
QoS
IGMP Snooping
User's Manual of GS-5220 Ultra PoE & PoE+ Series
1000 (Green), 10G (Orange)
Max. 439.4 watts/1498.3 BTU
AC 100~240V, 50/60Hz, 7A
DC 36~60V, 2A (GS-5220-16UP4S2X)
6KV DC
3 smart fan
IEEE 802.3af/802.3at/802.3bt Ultra PoE PSE
End-span/Mid-span/UPoE
Per port 54V DC, 75 watts (max.)
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),4/5(+), 7/8(-)
400 watts (max.)
24 units
13 units
6 units
Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow control disable/enable
Display each port's speed duplex mode, link status, flow control status,
auto-negotiation status, trunk status
TX/RX/Both
Many-to-1 monitor
802.1Q tagged based VLAN
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
IP subnet-based VLAN
MVR (Multicast VLAN registration)
Up to 255 VLAN groups, out of 4095 VLAN IDs
IEEE 802.3ad LACP/static trunk
11 groups with 6 port per trunk
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
Traffic classification based, strict priority and WRR
8-level priority for switching:
- Port number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/ToS field in IP packet
IGMP (v1/v2/v3) snooping, up to 255 multicast groups
IGMP querier mode support
30
