4.12.3 Access Management Statistics

This page provides statistics for access management. The Access Management Statistics screen in
Figure 4-12-3: Access Management Statistics Overview Page Screenshot
The page includes the following fields:
Object
• Interface
• Receive Packets
• Allow Packets
• Discard Packets
Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
: Clears all statistics.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Description
The interface that allowed remote host can access the switch.
The received packets number from the interface under access management
mode is enabled.
The allowed packets number from the interface under access management
mode is enabled.
The discarded packets number from the interface under access management
mode is enabled.
287
Figure 4-12-3 appears.
