4.14.6 Port Statistics

This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to
the whole switch, while local counters refers to counters for the currently selected switch. The LLDP Statistics screen in
4-14-5 appears.
The page includes the following fields:
Global Counters
Object
•
Neighbor entries were
last changed
•
Total Neighbors
Entries Added
•
Total Neighbors
Entries Deleted
•
Total Neighbors
Entries Dropped
•
Total Neighbors
Entries Aged Out
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-14-5: LLDP Statistics Page Screenshot
Description
It also shows the time when the last entry was last deleted or added. It also
shows the time elapsed since the last change was detected.
Shows the number of new entries added since switch reboot.
Shows the number of new entries deleted since switch reboot.
Shows the number of LLDP frames dropped due to that the entry table was full.
Shows the number of entries deleted due to Time-To-Live expiring.
