• Manufacturer
• Model
• IP Address
• MAC Address
• VLAN
• Select Device
Buttons
: Click to search the connecting ONVIF devices.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Auto-search : Automatic search occurs every 60 seconds.

4.19.2 ONVIF Device List

This page provides an overview of ONVIF Device entries. Each page shows up to 10 entries from the ONVIF Device List table,
default being 10, selected through the "entries per page" input field. When first visited, the web page will show the first 10 entries
from the beginning of the ONVIF Device List table; screen in
User's Manual of GS-5220 Ultra PoE & PoE+ Series
The ONVIF Device's Manufacturer of the entry.
The ONVIF Device's Model Name of the entry.
The ONVIF Device's IP Address of the entry.
The ONVIF Device's MAC address of the entry.
The ONVIF Device's VLAN ID of the entry.
Allows to tick for selecting ONVIF Devices for adding into ONVIF List Table.
Figure 4-19-2
Figure 4-19-2: ONVIF Device List Page Screenshot
356
appears.
