4.19.4 Floor Map

This page allows the clients for planning the ONVIF devices with the uploaded e-Map. It can select the ONVIF devices from
Device List and it also can modify the e-Map's Zoom and Scale; screen in
The page includes the following fields:
Object
• Summary Information
• Map Control
• Device List
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-19-3: Floor Map Page Screenshot
Description
Shows the number of Online and Offline ONVIF cameras.
Allows to choose Location of Map1/2/3 and zoom in/out of Map.
Allows to select ONVIF devices.
359
Figure 4-19-3 appears.
