The page includes the following fields:
Object
• MAP Select
• Description
• File size
• File
• Preview Map
• Current Map
Buttons
: Click to choose the file.
: Click to upload the file.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-19-3: Map Upload / Edit Page Screenshot
Description
Allows to select Map1/2/3 for uploading Map.
Indicates the map's description.
Shows Map's size.
Allows to choose and browse specific map file from laptop device.
The Preview use of Map.
The Current use of Map.
