Please press Add New Rule button to start settingPoE Schedule function. You have to set PoE schedule via profile and then go
back to PoE Port Configuration, and select "Schedule" mode from per port "PoE Mode" option and then you can indicate which
schedule profile could be apply to the PoE port.
The page includes the following fields:
Object
• Profile
• Week Day
• Start Hour
• Start Min
• End Hour
• End Min
• Reboot Enable
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-16-6: PoE Schedule Screenshot
Description
Set the schedule profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
Allows user to set week day for defining PoE function (should be enabled on the
day).
Allows user to set at what hour PoE function starts when enabled.
Allows user to set at what minute PoE function starts when enabled.
Allows user to set at what hour PoE function ends when disabled.
Allows user to set at what minute PoE function ends when disabled.
Allows user to enable or disable whole PoE port reboot by PoE reboot schedule.
Please note that if you want PoE schedule and PoE reboot schedule to work at the
same time, please use this function. Don't use Reboot Only function.
This function offers administrator to reboot PoE device at an indicated time if
