The page includes the following fields:
Server Statistics
Object
• Transmit to Server
• Transmit Error
• Receive from Server
• Receive Missing Agent
Option
• Receive Missing
Circuit ID
• Receive Missing
Remote ID
• Receive Bad Circuit ID
Receive Bad Remote ID
Client Statistics
Object
• Transmit to Client
• Transmit Error
• Receive from Client
• Receive Agent Option
• Replace Agent Option
• Keep Agent Option
• Drop Agent Option
Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
: Clears all statistics.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Description
The packets number that relayed from client to server.
The packets number that erroneously sent packets to clients.
The packets number that received packets from server.
The packets number that received packets without agent information options.
The packets number that received packets whose the Circuit ID option was
missing.
The packets number that received packets whose Remote ID option was
missing.
The packets number whose the Circuit ID option did not match known circuit ID.
The packets number whose the Remote ID option did not match known Remote
ID.
Description
The packets number that relayed packets from server to client.
The packets number that erroneously sent packets to servers.
The packets number that received packets from server.
The packets number that received packets with relay agent information option.
The packets number that replaced received packets with relay agent information
option.
The packets number that kept received packets with relay agent information
option.
The packets number that dropped received packets with relay agent information
option.
