• Reserved Power
(Reserved mode)
• PoE Temperature
• Current Power
Consumption
• Total Power Reserved
• Temperature 1
• Temperature 2
Local Port
PD Class
Power Used [W]
Current Used [mA]
• Priority
• Port Status
• Power Inline Mode
• Total
Buttons
Auto-refresh
:
Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.

4.16.7 PoE Schedule

This page allows the user to define PoE schedule and schedule power recycle.
PoE Schedule
Besides being used as an IP Surveillance, the Managed PoE switch is certainly applicable to constructing any PoE network
including VoIP and Wireless LAN. Under the trend of energy saving worldwide and contributing to the environmental protection
on the Earth, the Managed PoE switch can effectively control the power supply besides its capability of giving high watts power.
The "PoE schedule" function helps you to enable or disable PoE power feeding for each PoE port during specified time
intervals and it is a powerful function to help SMBs or enterprises save power and budget.
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Shows how much the total power is reserved for all PDs.
Displays the current operating temperature of the first PoE chip unit.
Shows the total watts usage of Managed PoE Switch.
Shows how much the total power is reserved for all PDs.
Displays the current operating temperature of the first PoE chip unit.
Displays the current operating temperature of the second PoE chip unit.
This is the logical port number for this row.
Displays the class of the PD attached to the port, as established by the classification
process. Class 0 is the default for PDs. The PD is powered based on PoE Class
level if system is working in Classification mode. A PD will return Class to 0 to 4 in
accordance with the maximum power drawn as specified by
The Power Used shows how much power the PD currently is using.
The Power Used shows how much current the PD currently is using.
The Priority shows the port's priority configured by the user.
The Port Status shows the port's status.
Displays per PoE port operating in mid-span, end-span or UPoE mode.
Shows the total power and current usage of all PDs.
337
Table
4-16-1.
