1. INTRODUCTION

Thank you for purchasing PLANET GS-5220 Ultra PoE & PoE+ Managed Switch series, which comes with multiple Gigabit
Ethernet copper and SFP/SFP+ fiber optic connectibility and robust Layer 2 and Layer 4 features. The descriptions of these
models are shown below:
Model Name
GS-5220-24P4X
GS-5220-24P4XR
GS-5220-24PL4X
GS-5220-24PL4XR
GS-5220-16UP4S2X
GS-5220-16UP4S2XR
GS-5220-24UP4X
GS-5220-24UP4XR
GS-5220-24UPL4X
GS-5220-24UPL4XR
GS-5220-48P4X
GS-5220-48P4XR
GS-5220-48PL4X
GS-5220-48PL4XR
"Managed Switch" is used as an alternative name in this user's manual.
1.1 Packet Contents
Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:

The Managed Switch

Quick Installation Guide

RJ45 to RS232 Cable

Rubber Feet

Two Rack-mounting Brackets with Attachment Screws

Power Cord

SFP Dust-proof Caps
Gigabit RJ45 Ports Gigabit SFP Slots
24
24
24
24
16
16
24
24
24
24
48
48
48
48
User's Manual of GS-5220 Ultra PoE & PoE+ Series
PoE Ports
4 combo 24
4 combo 24
4 combo 24
4 combo 24
4 16
4 16
4 combo 24
4 combo 24
4 combo 24
4 combo 24
- 48
- 48
- 48
- 48
10
10G SFP+ Slots PoE Budget
4 400
4 400
4 600
4 600
2 400
2 400
4 400
4 400
4 600
4 600
4 400
4 400
4 600
4 600
