4.8.13 MLD Snooping Status

This page provides MLD Snooping status. The IGMP Snooping Status screen in
The page includes the following fields:
Object
•
VLAN ID
•
Querier Version
•
Host Version
•
Querier Status
•
Querier Transmitted
• Querier Received
• V1 Reports Received
• V2 Reports Received
• V1 Leave Received
• Router Port
• Port
User's Manual of GS-5220 Ultra PoE & PoE+ Series
Figure 4-8-16: MLD Snooping Status Page Screenshot
Description
The VLAN ID of the entry.
Working Querier Version currently.
Working Host Version currently.
Shows the Querier status is "ACTIVE" or "IDLE".
"DISABLE" denotes the specific interface is administratively disabled.
The number of Transmitted Querier.
The number of Received Querier.
The number of Received V1 Reports.
The number of Received V2 Reports.
The number of Received V1 Leaves.
Display which ports act as router ports. A router port is a port on the Ethernet
switch that leads towards the Layer 3 multicast device or MLD querier.
Static denotes the specific port is configured to be a router port.
Dynamic denotes the specific port is learnt to be a router port.
Both denote the specific port is configured or learnt to be a router port.
Switch port number.
188
Figure 4-8-16 appears.
