900 Mhz Egsm And Edge; Table 6-2 Gsm/Egsm And Edge Power Per Carrier - ADC InterReach Fusion Installation, Operation And Reference Manual

6.3.3
D-620610-0-20 Rev D

900 MHz EGSM and EDGE

GSM/EGSM and EDGE Power per Carrier
Table 6-2
Power per Carrier (dBm)
No. of
Carriers GSM
1 16.0
2 13.0
3 11.0
4 10.0
5 9.0
6 8.0
7 7.5
8 7.0
9 6.5
10 6.0
11 5.5
12 5.0
13 5.0
14 4.5
15 4.0
16 4.0
20 3
30 1
Note: Operation at or above these output power levels may prevent Fusion
from meeting RF performance specifications or FCC Part 15 and EN55022
emissions requirements.
Help Hot Line (U.S. only): 1-800-530-9960
Maximum Output Power per Carrier
EDGE
16.0
13.0
11.0
10.0
9.0
8.0
7.5
7.0
6.5
6.0
5.5
5.0
5.0
4.5
4.0
4.0
3
1
6-7
CONFIDENTIAL
