800/900/1900 RAU
800 MHz (SMR) RF End-to-End Performance
Table 2-15
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
900 MHz (SMR) RF End-to-End Performance
Table 2-16
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
1900 MHz RF End-to-End Performance
Table 2-17
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
InterReach Fusion Installation, Operation, and Reference Manual
Typical
Downlink Uplink
15 15
2.5 3
38
–5
25
17
23
Typical
Downlink Uplink
15 15
2.5 3
35
–5
23
17
23
Typical
Downlink Uplink
15 15
3.5 4
38
–5
26
17
23
