SignalOn
®
RF Signal Management
Advanced broadband services are being developed and launched at an ever-accelerating
pace. While these services vary, they have one thing in common. Whether it be high-speed
data, video-on-demand, or IP telephony, broadband subscribers expect a reliable, high-quality
experience at an affordable price.
ADC's SignalOn
®
Series has been designed with these demanding service requirements in mind.
This next generation RF signal management platform provides unmatched density, RF performance,
and reliability—all at a competitive price. With its patented hitless "make-before-break" attenuator
circuit design, maintaining your RF signal network has never been easier.
w w w . a d c . c o m
Series
•
+ 1 - 9 5 2 - 9 3 8 - 8 0 8 0
•
1 - 8 0 0 - 3 6 6 - 3 8 9 1
Advertisement
Related Manuals for ADC RF Signal Management SignalOn Series
Summary of Contents for ADC RF Signal Management SignalOn Series
- Page 1 While these services vary, they have one thing in common. Whether it be high-speed data, video-on-demand, or IP telephony, broadband subscribers expect a reliable, high-quality experience at an affordable price. ADC’s SignalOn ® Series has been designed with these demanding service requirements in mind.
- Page 2 SignalOn Series ® RF Signal Management Typical Downstream Configuration IRD Receiver IRD Receiver IRD Receiver IRD Receiver IRD Receiver IRD Receiver IRD Receiver L-Band modulators IRD Receiver Satellite Splitters Receivers processors modulators Typical Upstream Configuration diagnostics/test gear QPSK set-top control network CMTS for HSD, VoIP w w w .
- Page 3 SignalOn Series ® RF Signal Management Chassis 32-Position, 4 RU Drawer Catalog Number N - C __ __ __ __ B Type 32-position, Drawer 20-position, Vertical 08H 8-position, Horizontal 04H 4-position, Horizontal 02H 2-position, Horizontal O r d e r i n g I n f o r m a t i o n Description Passive Chassis 32-position high-density chassis, 4 RU, black...
- Page 4 SignalOn Series ® RF Signal Management Passives: Introduction The SignalOn ® Series, combined with the innovative cable management of the chassis, provides engineers with a variety of products to simplify the RF signal management challenge. Passives: RF Splitter/Combiner Modules 5 MHz to 1 GHz Catalog Number N - M __ __ __ __ __ __ Module Type...
- Page 5 SignalOn Series ® RF Signal Management O r d e r i n g I n f o r m a t i o n Description Plain Splitter/Combiner Modules BNC connector 2:1 plain 4:1 plain 8:1 plain 3 x 2:1 plain 2 x 4:1 plain F connector 2:1 plain...
- Page 6 SignalOn Series ® RF Signal Management O r d e r i n g I n f o r m a t i o n Description Splitter/Combiner with Pad and Monitor Modules F connector 0 dB default 6 dB default w w w .
- Page 7 SignalOn Series ® RF Signal Management Passives: Directional Coupler Modules 5 MHz to 1 GHz Catalog Number N - MD __ __ __ __ __ Connector Type Circuit Quantity Single circuit Triple circuit O r d e r i n g I n f o r m a t i o n Description Directional Coupler Modules BNC connector...
- Page 8 SignalOn Series ® RF Signal Management Passives: Conditioning and Monitor Modules Features • Typically placed at the input to the forward path optical transmitter, this module allows for conditioning and grooming of the RF signal gain and slope. It is designed as 1:1 input to output with two MBB circuits in series for pad and EQ placement.
- Page 9 Passives: L-Band Satellite Splitter Modules 950 MHz to 2.15 GHz ADC’s new L-Band series satellite splitter modules are engineered for the highest performance in the 950 MHz to 2.15 GHz frequency range. These plain splitter/combiner modules feature dual port power-passing capability for powering LNB’s. All L-Band modules are available with precision F or BNC connectors, and are NEBS Level 3 compliant.
- Page 10 VoIP, VOD and HSD as applications evolve and your network changes. Leveraging over a decade of RF amplifier design experience, ADC’s SignalOn engineered to meet these demanding service requirements. Featuring operation from 50 MHz to 1 GHz, the amplifiers offer excellent performance and reliability.
- Page 11 SignalOn Series ® Actives: Forward Path Amplifier Actives: Amplifier Modules O r d e r i n g I n f o r m a t i o n Description Forward Path Amplifier Modules BNC connector F connector PeRFoRMANCe ATTRiBUTe Bandwidth optimum RF input Minimum full gain...
-
Page 12: Specifications
SignalOn Series ® RF Signal Management Actives: Power Supply Modules O r d e r i n g I n f o r m a t i o n Description Power Supply Modules AC to DC DC to DC Specifications PeRFoRMANCe ATTRiBUTe input voltage efficiency... - Page 13 Series ® RF Signal Management Actives: RF Switch Modules The ADC SignalOn RF Switch Module (RFSM) is designed for use with the ® SignalOn 8-position, or 20-position powered chassis. All RF connections to the switch are made through standard 75 W BNC, or F connectors on the rear of the module.
- Page 14 SignalOn Series ® RF Signal Management Actives: Reverse Path Amplifier Modules ADC’s Return Path Amplifier was designed specifically to solve problems particular to your environment. Providing greater density, unparalleled cable management, greater functionality and redundant powering, the return path amplifier...
- Page 15 SignalOn Series ® RF Signal Management Accessories O r d e r i n g I n f o r m a t i o n Description Cable Management Kits; (includes rack mount cable management rings) 2 brackets, 2 – 2.5" x 5.5" cable rings 4 brackets, 4 –...
- Page 16 Specifications published here are current as of the date of publication of this document. Because we are continuously improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
