D-620610-0-20 Rev D
Warning/Status Message for Expansion Hubs (continued)
Table C-7
Message
Number
/Default
Description
[E33]/W
Port 1 No DL test tone (Band 2).
[E34]/W
Port 2 No DL test tone (Band 2).
[E35]/W
Port 3 No DL test tone (Band 2).
[E36]/W
Port 4 No DL test tone (Band 2).
[E37]/W
Port 5 No DL test tone (Band 2).
[E38]/W
Port 6 No DL test tone (Band 2).
[E39]/W
Port 7 No DL test tone (Band 2).
[E40]/W
Port 8 No DL test tone (Band 2).
[E41]/W
Port 1 No DL test tone (Band 3).
[E42]/W
Port 2 No DL test tone (Band 3).
[E43]/W
Port 3 No DL test tone (Band 3).
[E44]/W
Port 4 No DL test tone (Band 3).
[E45]/W
Port 5 No DL test tone (Band 3).
[E46]/W
Port 6 No DL test tone (Band 3).
[E47]/W
Port 7 No DL test tone (Band 3).
[E48]/W
Port 8 No DL test tone (Band 3).
[E49]/W
Port 1 DL path loss is high.
[E50]/W
Port 2 DL path loss is high.
[E51]/W
Port 3 DL path loss is high.
[E52]/W
Port 4 DL path loss is high.
[E53]/W
Port 5 DL path loss is high.
[E54]/W
Port 6 DL path loss is high.
[E55]/W
Port 7 DL path loss is high.
[E56]/W
Port 8 DL path loss is high.
[E57]/W
Port 1 UL path loss is high.
[E58]/W
Port 2 UL path loss is high.
Help Hot Line (U.S. only): 1-800-530-9960
Reason/Action
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
C-17
