Table 2-7 900 Mhz Rf End-To-End Performance; Table 2-8 1800 Mhz Rf End-To-End Performance - ADC InterReach Fusion Installation, Operation And Reference Manual

D-620610-0-20 Rev D
900/1800 RAU
900 MHz RF End-to-End Performance
Table 2-7
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
1800 MHz RF End-to-End Performance
Table 2-8
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
Help Hot Line (U.S. only): 1-800-530-9960
System Specifications
Typical
Downlink Uplink
15 15
3 4
38
–5
26
17
23
Typical
Downlink Uplink
15 15
5
4.5
38
–5
26
17
23
2-13
