7.1.3
Equipment
Combination Cable Type
Repeater/BTS to Coaxial; N male
Fusion Main Hub connectors
Fusion Expansion CATV 75 Ohm;
Hub to RAU shielded F male con-
nectors
Main Hub to Expan- Multi-mode fiber:
sion Hub Single-mode fiber:
SC/APC male con-
nectors
RAU to passive Coaxial; N male
antenna connectors
7.2
7.2.1
D-620610-0-20 Rev D
NOTE: The proper crimp tool and die must be matched by the connector
type.

Distance Requirements

Table 7-1 shows the distances between Fusion components and related equipment.
Distance Requirements
Table 7-1
Cable Length
3–6 m (10–20 ft) typical
10 m (33 ft) maximum
• Minimum: 10 meters (33 ft)
• Maximum:
150 meters (492 ft) for RG-59;
170 meters (558 ft) for RG-6;
275 meters (902 ft) for RG-11
Refer to Table 5-1 and Table 5-2.
500 m (1640 ft.) maximum
6 km (19,685 ft.) maximum
1–3.5 m (3–12 ft) typical

Safety Precautions

Installation Guidelines

Use the following guidelines when installing ADC equipment:
Provide sufficient airflow and cooling to the equipment to prevent heat build-up
1.
from exceeding the maximum ambient air temperature specification. Do not com-
promise the amount of airflow required for safe operation of the equipment.
If you are removing the system, turn it off and remove the power cord first. There
2.
are no user-serviceable parts inside the components.
Help Hot Line (U.S. only): 1-800-530-9960
Safety Precautions
Additional Information
Limited by loss and noise.
Refer to your link budget
calculation.
Limited by CE Mark require-
ments.
Refer to "System Gain" on
page 6-11.
Limited by 3 dB optical
attenuation
Limited by loss and noise.
Refer to your link budget
calculation.
CONFIDENTIAL
7-3
