System Specifications
2-14
CONFIDENTIAL
900/2100 RAU
900 MHz RF End-to-End Performance
Table 2-9
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
2100 MHz RF End-to-End Performance
Table 2-10
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Spurious Output Levels (dBm)
UMTS TDD Band Spurious Output Level
1900–1920 MHz, 2010–2025 MHz (dBm/MHz)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
850/1800 RAU
850 MHz RF End-to-End Performance
Table 2-11
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
InterReach Fusion Installation, Operation, and Reference Manual
Typical
Downlink Uplink
15 15
3 4
38
–5
26
17
23
Typical
Downlink Uplink
15 15
4.5 5
<–30
<–52
38
–5
26
17
23
Typical
Downlink Uplink
15 15
2.5 3
38
–5
26
16
22
D-620610-0-20 Rev D
