C.4
D-620610-0-20 Rev D

Faults for RAUs

Faults for RAUs
Table C-4
Message
Number Description
{RF01} Software error occurred and recovered.
{RF02} Software error occurred and recovered.
{RF03} Software error occurred and recovered.
{RF04} Software reset occurred and recovered,
or firmware download.
{RF05} Software error occurred and recovered.
{RF06} Problem detected in the RAU.
{RF07} RAU power cycle.
{RF08} Problem detected in the RAU.
{RF09} Invalid band.
{RF10} Low input DC voltage.
{RF11} Hardware Failure (DL PLL Band 1).
{RF12} Hardware Failure (DL PLL Band 2).
{RF13} Hardware Failure (DL PLL Band 3).
{RF14} Hardware Failure (UL PLL Band 1).
{RF15} Hardware Failure (UL PLL Band 2).
{RF16} Hardware Failure (UL PLL Band 3).
{RF17} Hardware Failure (PA Band 1).
{RF18} Hardware Failure (PA Band 2).
{RF19} Hardware Failure (PA Band 3).
{RF20} Hardware Failure (UL Pilot).
{RL21} Commanded Out-of-service (Band 1).
{RL22} Commanded Out-of-service (Band 2).
{RL23} Commanded Out-of-service (Band 3).
{RF24} Problem detected in the RAU.
{RX25} Commanded shutdown (Band 1).
{RX26} Commanded shutdown (Band 2).
{RX27} Commanded shutdown (Band 3).
{RF28} Internal shutdown (Band 1).
{RF29} Internal shutdown (Band 2).
{RF30} Internal shutdown (Band 3).
{RF31} Problem detected in the system.
{RF32} Problem detected in the RAU.
Help Hot Line (U.S. only): 1-800-530-9960
Reason/Action
If this happens repeatedly, replace the RAU.
If this happens repeatedly, replace the RAU.
If this happens repeatedly, replace the RAU.
If this happens repeatedly, replace the RAU.
If this happens repeatedly, replace the RAU.
Contact ADC Support for more information.
RAU power cycle.
Contact ADC Support for more information.
The RAU doesn't support programmed band. Check the
RAU type against the band programmed in the hub.
Check the coaxial cable for high RF loss. Try another
Hub port. If the fault persists, replace the RAU. If the
fault clears, mark the Hub port as unusable and replace
the Hub when possible.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Cycle power once. If the fault persists, replace the RAU.
Band 1 commanded out-of-service by User. Command
In-Service on Band 1 to restore service.
Band 2 commanded out-of-service by User. Command
In-Service on Band 2 to restore service.
Band 3 commanded out-of-service by User. Command
In-Service on Band 3 to restore service.
Contact ADC Support for more information.
Check the status of hub to which the RAU is connected.
Check the status of hub to which the RAU is connected.
Check the status of the hub to which the RAU is con-
nected.
RAU Fault condition in band 1 path (or common path).
RAU Fault condition in band 2 path (or common path).
RAU Fault condition in band 3 path (or common path).
Contact ADC Support for more information.
Contact ADC Support for more information.
C-9
