Alarm Monitoring Connectivity Options
7.8.6
PC running
Standard Browser
Software
7-74
CONFIDENTIAL
Ethernet LAN Connection
An Ethernet LAN connection can be used to communicate between the PC and
Fusion. Testing was performed with an Linksys 4-port LAN switch.
OA&M Connection Using Ethernet and ENET/232 Serial Hub
Figure 7-58
TCP/IP
Ethernet
InterReach Fusion Installation, Operation, and Reference Manual
100 BASE-T Cable
RJ-45 to RJ-45 male
LAN
Switch
Ethernet
D-620610-0-20 Rev D
