Figure 7-27 Duplex Base Station To A Fusion Main Hub - ADC InterReach Fusion Installation, Operation And Reference Manual

Note: This applies to either Band 1, Band 2, Band 3.
D-620610-0-20 Rev D
Duplex Base Station to a Fusion Main Hub
Figure 7-27
Band 1
UL1
Alarms
Insert attenuator, if needed
Help Hot Line (U.S. only): 1-800-530-9960
Interfacing the Fusion Main Hub to an RF Source
Band 2 Band 3
UL3
UL2
DL2 DL3
DL1
N-male to N-male
Coaxial Cable
Circulator
N-male to N-male
Coaxial Cable
Duplex
Base Station
AC Power
T1/E1 to
Mobile
Switching
Center
CONFIDENTIAL
7-47
