C.2
D-620610-0-20 Rev D

Faults Reported for System CPU

Faults for System CPU
Table C-2
Message
Number Description
{SF01} No internal communications.
{SF02} Unable to open file (sysinfo).
{SF03} Unable to open file (sysstat).
{SF04} Invalid internal response.
{SF05} No MAC address.
{SF06} Unable to open file (sysinfo_org).
{SF07} Unable to open file (sbc_status).
{SF08} Invalid internal field response.
{SF09} Unable to open file (fileTTL).
{SF10} Invalid internal ASCII response.
{SF11} Unable to open file (sysalarm).
{SF12} Unable to open file (password_etb).
{SF13} Unable to open file (CRC).
{SF14} Problem detected in the System CPU.
{SF15} pThread not executing.
{SF16} Problem detected in the System CPU.
{SF17} Problem detected in the System CPU.
{SF18} Problem detected in the System CPU.
{SF19} Problem detected in the System CPU.
{SF20} Problem detected in the System CPU.
{SF21} Problem detected in the System CPU.
{SF22} Problem detected in the System CPU.
{SF23} Problem detected in the System CPU.
{SF24} Problem detected in the System CPU.
{SF25} Problem detected in the System CPU.
{SF26} Problem detected in the System CPU.
{SF27} Problem detected in the System CPU.
{SF28} Problem detected in the System CPU.
{SF29} Problem detected in the System CPU.
{SF30} Problem detected in the System CPU.
{SF31} Problem detected in the System CPU.
{SF32} Problem detected in the System CPU.
Help Hot Line (U.S. only): 1-800-530-9960
Reason/Action
No internal communications in preceding 2 minutes.
Power cycle to clear.
System CPU rebooted.
System CPU rebooted.
System CPU rebooted, internal command does not
return valid response after 4 retries.
System CPU rebooted, unable to read MAC address
from the Ethernet driver.
System CPU rebooted.
System CPU rebooted.
System CPU rebooted, internal command format
invalid.
System CPU rebooted.
System CPU rebooted, illegal number of bytes.
System CPU rebooted.
System CPU rebooted.
System CPU rebooted.
Contact ADC Support for more information.
System CPU rebooted.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
C-5
