Warnings/Status Messages for Main Hubs (continued)
Table C-5
Message
Number/
Default Description
[M92]/W Port 4 UL path loss is high.
[M93]/W Port 5 UL path loss is high.
[M94]/W Port 6 UL path loss is high.
[M95]/W Port 7 UL path loss is high.
[M96]/W Port 8 UL path loss is high.
[M97]/W Port 1 UL path exceeds maximum
gain.
[M98]/W Port 2 UL path exceeds maximum
gain.
[M99]/W Port 2 UL path exceeds maximum
gain.
[M100]/W Port 2 UL path exceeds maximum
gain.
[M101]/W Port 2 UL path exceeds maximum
gain.
[M102]/W Port 2 UL path exceeds maximum
gain.
[M103]/W Port 2 UL path exceeds maximum
gain.
[M104]/W Port 8 UL path exceeds maximum
gain.
[M105]/W Port 1 54 VDC Power Enabled.
[M106]/W Port 2 54 VDC Power Enabled.
[M107]/W Port 3 54 VDC Power Enabled.
[M108]/W Port 4 54 VDC Power Enabled.
[M109]/W Port 5 54 VDC Power Enabled.
[M110]/W Port 6 54 VDC Power Enabled.
[M111]/W Port 7 54 VDC Power Enabled.
[M112]/W Port 8 54 VDC Power Enabled.
InterReach Fusion Installation, Operation, and Reference Manual
Reason/Action
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
If the problem is common to more than one port, replace
the Hub, otherwise check the RAU.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
Caution: Port 54 VDC power may be present at the output.
