Connecting Multiple Fusion Main Hubs to a Duplex Repeater or
BTS
WARNING: Only ADC personnel or ADC-authorized installation per-
sonnel should connect the Fusion Main Hub to a base station or
repeater. Exceeding the maximum input power could cause failure of
the Fusion Main Hub (refer to Section 5.2 on page 5-4 for maximum power spec-
ifications). If the maximum composite power is too high, attenuation is required.
Considerations:
• 2 hybrid power combiner/splitters; one for uplink and one for downlink (2x1 for
two Fusion Main Hubs, 3x1 for three, 4x1 for four, and so.)
• 2 N-male to N-male coaxial jumper cables to connect each Fusion Main Hub's RF
Band to the power combiner/splitters
• 1 circulator
• 1 N-male to N-male coaxial jumper cable between each circulator and the repeater
or base station
• 1 N-male to N-male coaxial jumper cable between each circulator and power com-
biner/splitter
Procedure:
Connect the circulator to the repeater or base station using one N-male to N-male
1.
coaxial jumper cable.
Connect each power combiner/splitter to the circulator using one N-male to
2.
N-male coaxial jumper cable per combiner/splitter.
Connect the power combiner/splitter to the Hubs using N-male to N-male coaxial
3.
jumper cable:
From the first Hub's
a.
power combiner/splitter
From the first Hub's
b.
ond power combiner/splitter
From the second Hub's
c.
power combiner/splitter
From the second Hub's
d.
second power combiner/splitter
NOTE: Connections should not cross Bands. For example, all Band 1 connections
should be made to the same hybrid power combiner/splitter connected to the repeater
BTS that matches the Band 1 frequency.
Check Hub LEDs.
4.
Help Hot Line (U.S. only): 1-800-530-9960
Interfacing the Fusion Main Hub to an RF Source
(Band 1, Band 2, or Band 3) port to the first
UPLINK
(Band 1, Band 2, or Band 3) port to the sec-
DOWNLINK
(Band 1, Band 2, or Band 3) port to the first
UPLINK
(Band 1, Band 2, or Band 3) port to the
DOWNLINK
7-53
