ADC InterReach Fusion Installation, Operation And Reference Manual page 221

Table of Contents

D-620610-0-20 Rev D

Fault Messages for Main Hubs (continued)

Table C-1

Message

Number

Description

{MF33}

Hardware failure (DL PLL Band 3).

{MF34}

Hardware failure (UL PLL Band 3).

{ML35}

Commanded Out-of-service (Band 3).

{MF36}

Hardware failure (638 MHz PLL).

{MF37}

Hardware failure (638 MHz PLL).

{MF38}

Problem detected in the Hub.

{MF39}

Problem detected in the Hub.

{MF40}

Problem detected in the Hub.

{MF41}

Hardware failure (Optical Power Out).

{MF42}

Unable to sync with TDD frame (Band 1).

{MF43}

Unable to sync with TDD frame (Band 2).

{MF44}

Problem detected in the Hub.

{MF45}

Problem detected in the Hub.

{MF46}

Problem detected in the Hub.

{MF47}

Problem detected in the Hub

{MF48}

Problem detected in the Hub.

{MD129}

Port 1 Disconnected.

{MD130}

Port 2 Disconnected.

{MD131}

Port 3 Disconnected.

{MD132}

Port 4 Disconnected.

{MD133}

Port 5 Disconnected.

{MD134}

Port 6 Disconnected.

{MD135}

Port 7 Disconnected.

{MD136}

Port 8 Disconnected.

{MC137}

Port 1 No Communications.

{MC138}

Port 2 No Communications.

{MC139}

Port 3 No Communications.

{MC140}

Port 4 No Communications.

{MC141}

Port 5 No Communications.

{MC142}

Port 6 No Communications.

{MC143}

Port 7 No Communications.

{MC144}

Port 8 No Communications.

{MT145}

Port 1 Cable Fault.

{MT146}

Port 2 Cable Fault.

{MT147}

Port 3 Cable Fault.

{MT148}

Port 4 Cable Fault.

{MT149}

Port 5 Cable Fault.

Help Hot Line (U.S. only): 1-800-530-9960

Reason/Action

Cycle power once. If fault persists, replace the Hub.

Band 3 commanded out-of-service by User.

Cycle power once. If fault persists, replace the Hub.

Contact ADC Support for more information.

Cycle power once. If the fault persists, replace the

Hub.

Check input signal and/or user TDD settings.

Contact ADC Support for more information

Contact ADC Support for more information.

Unit is disconnected.

No communications with remote unit.
