Fiber Optical Cables - ADC InterReach Fusion Installation, Operation And Reference Manual

A.2
D-620610-0-20 Rev D
System Gain (Loss) Relative to CATV Cable Length for 800/900/1900
Table A-2
RAUs
Comm-
Scope
Cable Part Plenum
Type Number Rated
RG-59
2065V Yes
2022V Yes
5572R No
5565 No
RG-6
2279V Yes
2275V Yes
5726 No
5765 No
RG-11
2293K Yes
2285K Yes
5913 No
* Exceeding the distance of copper-clad cable will result in the attached RAU becoming non-functional. If
the distance of a cable run is at its maximum and is of concern, ADC recommends the use of solid copper
cable to ensure successful operation.

Fiber Optical Cables

• Connects the Main Hub to Expansion Hub(s)
• Transmits (downlink) and receives (uplink) optical signals
• Carries configuration and status information
• Use industry-standard 62.5μm/125μm MMF or Corning SMF-28 fiber, or equiva-
lent.
• SC/APC (angle-polished) connectors are required throughout the fiber network
(port-to-port), including fiber distribution panels
Help Hot Line (U.S. only): 1-800-530-9960
Solid Copper
Copper Clad
Conductor Conductor
X
X
X
X
X
X
X
X
X
X
X
Distance
Where
Zero-loss RF is
RF 10dB
Maximum Below
Length Input RF
(meters) (meters)
150 210
80 80*
70 70*
150 210
170 230
115 115*
110 110*
170 230
275 375
240 240*
240 240*
A-7
