Fusion Main Hub Front Panel

3.2
1 2
1 2
6
3-4
CONFIDENTIAL
Fusion Main Hub Front Panel
Fusion Main Hub Front Panel
Figure 3-3
1 2
1 2
Four fiber optic ports (labeled
1.
• One standard female SC/APC connector per port for MMF/SMF input (labeled
)
UPLINK
• One standard female SC/APC connector per port for MMF/SMF output
(labeled
DOWNLINK
Four sets of fiber port LEDs (one set per port)
2.
• One LED per port for port link status and downstream unit status
One set of unit status LEDs
3.
• One LED for unit power status (labeled
• One LED for unit status (labeled
One 9-pin D-sub male connector for system remote dial-up communication and
4.
diagnostics using a modem (labeled
One RJ-45 female connector for system communication and diagnostics using a
5.
PC/laptop with direct connect or using a LAN switch (labeled
Power switch
6.
NOTE: The Fusion One Port Main Hub (PN: FSN-1-MH-1P) configuration
is a cost reduced version of the Fusion Main Hub and supports only one
Expansion Hub (up to 8 RAUs).
InterReach Fusion Installation, Operation, and Reference Manual
3
4
, ,
PORT 1 PORT 2
)
POWER
MAIN HUB STATUS
)
MODEM
5
, )
PORT 3 PORT 4
)
)
ADMIN/LAN
