C.7
C-16
CONFIDENTIAL
Messages for Expansion Hubs
Warning/Status Message for Expansion Hubs
Table C-7
Message
Number
/Default Description
[E01]/W Alarm Input 1.
[E02]/W Alarm Input 2.
[E03]/W Alarm Input 3.
[E04]/S Problem detected in the EH.
[E05]/W SNMP Trap #1.
[E06]/W SNMP Trap #2.
[E07]/W SNMP Trap #3.
[E08]/S Problem detected in the EH.
[E09]/S Fan 1 failure.
[E10]/S Fan 2 failure.
[E11]/W -5 VDC Monitor.
[E12]/W 5 VDC Monitor.
[E13]/W 9 VDC Monitor.
[E14]/W 54 VDC Pwr Supply failure.
[E15]/W 3 VDC Monitor.
[E16]/W 12 VDC Monitor.
[E17]/W Temperature High.
[E18]/W DL path exceeds maximum gain.
[E19]/W DL path loss is high.
[E20]/W Hardware Failure (High UL
Pilot).
[E21]/W Hardware Failure (Low UL
Pilot).
[E22]/W Low optical input power.
[E23]/W High laser current.
[E24]/S Problem detected in the EH.
[E25]/W Port 1 No DL test tone (Band 1).
[E26]/W Port 2 No DL test tone (Band 1).
[E27]/W Port 3 No DL test tone (Band 1).
[E28]/W Port 4 No DL test tone (Band 1).
[E29]/W Port 5 No DL test tone (Band 1).
[E30]/W Port 6 No DL test tone (Band 1).
[E31]/W Port 7 No DL test tone (Band 1).
[E32]/W Port 8 No DL test tone (Band 1).
InterReach Fusion Installation, Operation, and Reference Manual
Reason/Action
Check the equipment connected to alarm input 1.
Check the equipment connected to alarm input 2.
Check the equipment connected to alarm input 3.
Contact ADC Support for more information.
TBD.
TBD.
TBD.
Contact ADC Support for more information.
Check the fan for proper rotation, air flow blockage, and dust
accumulation. Replace the Hub on high temperature warning.
Check the fan for proper rotation, air flow blockage, and dust
accumulation. Replace the Hub on high temperature warning.
DC power out of range, replace the Hub.
DC power out of range, replace the Hub.
DC power out of range, replace the Hub.
DC port power supply out of range, replace the Hub.
DC power out of range, replace the Hub.
DC power out of range, replace the Hub.
Reduce the ambient temperature, check for air flow blockage,
fan rotation.
If the problem is common to more than one port, replace the
MH, otherwise check the EH.
Check the cable for high RF loss. Switch the cable connec-
tion to a different MH port. If the problem is on more than
one port, replace the EH, otherwise replace the RAU.
Cycle power once. If the fault persists, replace the EH.
Cycle power once. If the fault persists, replace the EH.
Check the downlink fiber connection.
Contact ADC Support for more information.
Contact ADC Support for more information.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
Hub/Port DL path gain is low.
D-620610-0-20 Rev D
