Warnings/Status Messages for Main Hubs (continued)
Table C-5
Message
Number/
Default Description
[M66]/S Problem detected in the Hub.
[M67]/S Problem detected in the Hub.
[M68]/S No UL test tone (Port 4/Band 1).
[M69]/S No UL test tone (Band 2).
[M70]/S No UL test tone (Port 2/Band 2).
[M71]/S No UL test tone (Port 3/Band 2).
[M72]/S No UL test tone (Port 4/Band 2).
[M73]/S No UL test tone (Band 3).
[M74]/S No UL test tone (Port 2/Band 3).
[M75]/S No UL test tone (Port 3/Band 3).
[M76]/S No UL test tone (Port 4/Band 3).
[M77]/S Problem detected in the Hub.
[M78]/S Problem detected in the Hub.
[M79]/S Problem detected in the Hub.
[M80]/S Problem detected in the Hub.
[M81]/W Port 1 DL path loss is high.
[M82]/W Port 2 DL path loss is high.
[M83]/W Port 3 DL path loss is high.
[M84]/W Port 4 DL path loss is high.
[M85]/W Port 5 DL path loss is high.
[M86]/W Port 6 DL path loss is high.
[M87]/W Port 7 DL path loss is high.
[M88]/W Port 8 DL path loss is high.
[M89]/W Port 1 UL path loss is high.
[M90]/W Port 2 UL path loss is high.
[M91]/W Port 3 UL path loss is high.
Help Hot Line (U.S. only): 1-800-530-9960
Reason/Action
Contact ADC Support for more information.
Contact ADC Support for more information.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Hub/Port UL path gain is low.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
Contact ADC Support for more information.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
If the problem is on more than one port, replace the Hub.
Switch the cable connection to a different hub port until the
Hub can be replaced.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem on more than one
port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
Check the cable for high RF loss. Switch the cable connec-
tion to a different hub port. If the problem is on more than
one port, replace the Hub, otherwise replace the RAU.
