System Specifications
2.6.1
2-12
CONFIDENTIAL

RF End-to-End Performance

The following tables list the RF end-to-end performance of each protocol.
NOTE: The system gain is adjustable in 1 dB steps from 0 to 15 dB, and the
gain of each RAU can be attenuated 0 or 10 dB.
850/1900 RAU
850 MHz RF End-to-End Performance
Table 2-5
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
1900 MHz RF End-to-End Performance
Table 2-6
Parameter
Average gain with 150 m RG-59 at 25°C (77°F) (dB)
Ripple with 150 m RG-59 (dB)
Output IP3 (dBm)
Input IP3 (dBm)
Output 1 dB Compression Point (dBm)
Noise Figure 1 MH, 1 EH, 8 RAUs (dB)
Noise Figure 1 MH, 4 EH, 32 RAUs (dB)
InterReach Fusion Installation, Operation, and Reference Manual
Typical
Downlink Uplink
15 15
2.5 3
38
–5
26
16
22
Typical
Downlink Uplink
15 15
3.5 4
38
-5
26
17
23
D-620610-0-20 Rev D
