Expansion Hub Rear Panel; Figure 4-4 Expansion Hub Rear Panel; Table 4-2 Fusion Expansion Hub Port Led States - ADC InterReach Fusion Installation, Operation And Reference Manual

PORT
PORT
PORT
PORT
PORT
4.3
1
D-620610-0-20 Rev D
steady green
steady red
flashing red (60 pulses per minute [PPM])
Fusion Expansion Hub Port LED States
Table 4-2
LED State Indicates
Off • The RAU is not connected.
• The RAU is connected.
Green
• No faults from the RAU.
Red • The RAU was disconnected.
(60 PPM)
• The RAU is not communicating.
• The RAU port power is tripped.
Red • The RAU is disconnected.
(Steady)
• The RAU is reporting a fault.
Green • The RAU is disconnected.
(60-ppm)
• The RAU is reporting a lockout condition.

Expansion Hub Rear Panel

Expansion Hub Rear Panel
Figure 4-4
AC power cord connector
1.
Two air exhaust vents
2.
