SECTION 8
8.1
D-x620610-0-20 Rev D

Replacing Fusion Components

This section contains the following subsections:
• Section 8.1 Replacing an RAU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
• Section 8.2 Replacing a Fusion Expansion Hub . . . . . . . . . . . . . . . . . . . . . . . 8-3
• Section 8.3 Replacing a Fusion Main Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

Replacing an RAU

Be aware that the new RAU must support the same bands as the one you are replac-
ing. If the RAU is of the wrong band combination, it will not operate properly in the
system.
Replacing an RAU
Using AdminBrowser, log in and click
1.
Click S S
2.
HOW YSTEM
.
MATION
All system settings for Hubs and RAUs will be displayed. Write down or save the
Uplink and Downlink Attenuation setting so you can set the new RAU with the
same settings.
Click to close the window.
C
3.
ANCEL
Verify that the new RAU is of the same frequency bands as the one replaced.
4.
Disconnect the CATV cable and antenna cable from the unit to be replaced.
5.
Install the new RAU.
6.
Connect the antenna cable and then the CATV cable to the new RAU.
7.
Click
S C
8.
YSTEM ONFIGURATION
Click S S
9.
HOW YSTEM
Select the Fusion RAU replaced and click
10.
InterReach Fusion Installation, Operation, and Reference Manual
S
YSTEM
T , select Fusion Main Hub, and click
REE
.
T .
REE
E
DIT
.
I
NFORMATION
G S
ET YSTEM
.
U P
NIT ROPERTIES
CONFIDENTIAL
I -
NFOR
8-1
