used and which Expansion Hub the cables are intended for. This differentiates the
connectors for proper connection between the Main Hub and Expansion Hubs.
For example:
First pair to Main Hub port 1: 11 (uplink), 12 (downlink);
Second pair to Main Hub port 2: 21 (uplink), 22 (downlink);
Third pair to Main Hub port 3: 31 (uplink), 32 (downlink); and so on.
NOTE: The Fusion One Port Main Hub (PN: FSN-1-MH-1P) configuration
is a cost reduced version of the Fusion Main Hub and supports only one
Expansion Hub (up to 8 RAUs).
If the fiber jumper is labeled with
Connect s to
1. 1 UPLINK
Connect s to
2. 2 DOWNLINK
Record which cable number and port number you connected to
3.
.
DOWNLINK
This information is needed when connecting the other end of the fiber cable to the
Expansion Hub's fiber ports.
The fiber port LEDs should be off, indicating that the Expansion Hub(s) are not
connected.
If the fiber jumper is color-coded (for example, "blue" or "red"):
Connect "blue" to
1. UPLINK
Connect "red" to
2. DOWNLINK
Record which color and port number you connected to
3.
This information is needed when connecting the other end of the fiber cable to the
Expansion Hub's fiber ports.
The fiber port LEDs should be off, indicating that the Expansion Hub(s) are not
connected.
Help Hot Line (U.S. only): 1-800-530-9960
or :
1 2
ports on the Main Hub.
ports on the Main Hub.
ports on the Main Hub.
ports on the Main Hub.
Fusion Installation Procedures
and
UPLINK
and
UPLINK DOWNLINK
