5.4
5.5
D-620610-0-20 Rev D

Faults and Warnings

Both fault and warning conditions are reported to the Fusion Hub where they are
stored. Only faults are indicated by the faceplate LEDs.
For more information, refer to Appendix C.

Remote Access Unit Specifications

Remote Access Unit Specifications
Table 5-5
Specification
u u
Dimensions (H W D)
Weight
Operating Temperature
Non-operating Temperature
Operating Humidity, non-condensing
RF Connectors
LED Alarm and Status Indicators
Maximum Heat Dissipation (W)
MTBF
NOTE: For system performance, it is important that you use only low loss,
solid copper center conductor CATV cable with quality F connectors that use
captive centerpin conductors. Refer to Appendix A for more information.
Help Hot Line (U.S. only): 1-800-530-9960
Description
54 mm × 286 mm × 281 mm
(2.13 in. × 11.25 in. × 11.13 in.)
< 2.1 kg (< 4.6 lb.)
–25° to +45°C (–13° to +113°F)
–25° to +85°C (–13° to +185°F)
5% to 95%
One Type-F, female (CATV - 75 ohms)
One Type-N, female (antenna 50 ohms)
Unit Status (1 pair):
• Link
• Alarm
50 typical, 64 max (from the Hub)
211,600 hours (All Dual Band RAUs)
144,409 hours (800/900/1900 Tri-Band RAUs)
Faults and Warnings
5-7
