SPX FLOW Universal TS Series Instruction Manual page 111

Waukesha Cherry-Burrell Brand Universal TS Series
ITEM NO. DESCRIPTION
1 Nut, Acorn
2 Cover
Gasket, Cover, EPDM
3 Gasket, Cover, FKM
Gasket, Cover, FFKM
4 Nut, Screw
Screw Nut O-ring EPDM
* 5
Screw Nut O-ring FKM
Screw Nut O-ring FFKM
6 Washer-Belleville
Washer Retainer O-ring EPDM
* 7
Washer Retainer O-ring FKM
Washer Retainer O-ring FFKM
Left Hand Screw - 45 Pitch
8
Left Hand Screw - 60 Pitch
Left Hand Screw - 90 Pitch
Right Hand Screw - 45 Pitch
9
Right Hand Screw - 60 Pitch
Right Hand Screw - 90 Pitch
10 Mechanical Seal Assembly
11 Body Retaining Screw
12 Cover Short Dowel Pin
13 Cover Short Dowel Pin
14 Bushing, Dowel Pin
15 Bushing, Dowel Pin
16 Pump Body
17 Gear Case Assy
18 SHCS 10-32x.50 18-8 SS
19 Stud, Standard Cover
20 Gear Case Dowel
21 Gear Case Dowel
22 Eye Bolt 1/2-13 x .75 304SS
Notes:
* Recommended spare part
1. See "Universal Twin Screw Seal Parts" on page 113.
2. On the 220-UTS, this gasket is installed in the body, not the cover.
POA: Contact customer service for part number.
06/2017
220-UTS Parts
QTY PER
PUMP
95-03141
PART NO. NOTES
8 108372+
1 POA
137433+
1
137431+
137432+
2 137608+
E70235
2
V70235
K70235
2 101694+
E70122
2
V70122
K70122
137375+
1
136801+
137377+
137374+
1
136800+
137376+
2 POA
2 137099+
1 137005+
1 137004+
1 CD0116100
1 CD0116000
1 POA
1 POA
6 30-243
8 108844+
1 124584+
1 124586+
3 30-721
PL5060-CH145
Parts List
2
1
