SPX FLOW Universal TS Series Instruction Manual page 103

Waukesha Cherry-Burrell Brand Universal TS Series
ITEM NO. DESCRIPTION
1 Nut, Acorn
2 Cover
Gasket, Cover, EPDM
3
* Gasket, Cover, FKM
Gasket, Cover, FFKM
4 Nut, Screw
Screw Nut O-ring EPDM
* 5
Screw Nut O-ring FKM
Screw Nut O-ring FFKM
6 Washer-Belleville
Washer Retainer O-ring EPDM
* 7
Washer Retainer O-ring FKM
Washer Retainer O-ring FFKM
Left Hand Screw - 16.8 Pitch
8 Left Hand Screw - 28 Pitch
Left Hand Screw - 42 Pitch
Right Hand Screw - 16.8 Pitch
9 Right Hand Screw - 28 Pitch
Right Hand Screw - 42 Pitch
Mechanical Seal Assembly
10
Body Retaining Screw
11
Cover Short Dowel Pin
12
Cover Short Dowel Pin
13
Bushing, Dowel Pin
14
Bushing, Dowel Pin
15
Pump Body
16
Gear Case Assy
17
SHCS 8-32 x .500" 18-8SS
18
Stud, Standard Cover
19
Gear Case Dowel
20
Gear Case Dowel
21
22 Eye Bolt 3/8-16 X .56"LG 304
Notes:
* Recommended spare part
1. See "Universal Twin Screw Seal Parts" on page 113.
POA: Contact customer service for part number.
06/2017
030-UTS Parts
QTY PER
PUMP
95-03141
PART NO. NOTES
8 108370+
1 POA
137427+
1
137425+
137426+
2 101805+
E70130
2
V70130
K70130
2 101692+
E70115
2 V70115
K70115
137367+
1 136795+
137369+
137366+
1 136794+
137368+
2 POA
2 137097+
1 137002+
1 137001+
1 BD0116100
1 BD0116000
1 POA
1 POA
6 137460+
8 137069+
1 124582+
1 124583+
2 30-720
PL5060-CH141
Parts List
1
Page 101
