Parts List

Non-Marring Socket Tool for Screw Nuts

UTS Shaft Locking Tool

Screw Blocking Tool

1
As assembled

Gear Tools

Description
Gear Nut Driver
Gear Nut Driver
Gear Nut Driver
Gear Nut Driver
Gear End Shaft Thread Chaser
Gear End Shaft Thread Chaser
Gear End Shaft Thread Chaser
Gear End Shaft Thread Chaser
Page 114
Waukesha Cherry-Burrell Brand Universal TS Series

Special Tools

Pump Model
015-UTS
030-UTS
130-UTS
220-UTS
Pump Model Part Number
015-UTS 139526+
030-UTS 139527+
130-UTS 139528+
220-UTS 139529+
PL5060-CH151
Item Description
2
Pump Model Part Number
015-UTS 109281+
030-UTS 109282+
130-UTS 109283+
220-UTS 110304+
015-UTS 109287+
030-UTS 109288+
130-UTS 109289+
220-UTS 110305+
PL5060-CH147
95-03141
Part Number
126533+
126534+
126257+
126535+
PL5060-CH136

O-ring Removal Tool

Description
O-ring removal tool
1 Screw Blocking Dowel
2 Screw Wedge
Part Number
AD0096001
PL5060-CH130
Part Number
139245+
139244+
PL5060-CH148
06/2017
