130-Uts Parts - SPX FLOW Universal TS Series Instruction Manual

Waukesha Cherry-Burrell Brand Universal TS Series
ITEM NO. DESCRIPTION
1 Nut, Acorn
2 Cover
Gasket, Cover, EPDM
3
* Gasket, Cover, FKM
Gasket, Cover, FFKM
Nut, Screw
4
Screw Nut O-ring EPDM
* 5
Screw Nut O-ring FKM
Screw Nut O-ring FFKM
Washer-Belleville
6
Washer Retainer O-ring EPDM
* 7
Washer Retainer O-ring FKM
Washer Retainer O-ring FFKM
Left Hand Screw - 36.7 Pitch
8 Left Hand Screw - 55 Pitch
Left Hand Screw - 73.4 Pitch
Right Hand Screw - 36.7 Pitch
9 Right Hand Screw - 55 Pitch
Right Hand Screw - 73.4 Pitch
Mechanical Seal Assembly
10
Body Retaining Screw
11
Cover Short Dowel Pin
12
Cover Short Dowel Pin
13
Bushing, Dowel Pin
14
15 Bushing, Dowel Pin
16 Pump Body
17 Gear Case Assy
18 SHCS 10-32x.50 18-8 SS
19 Stud, Standard Cover
20 Gear Case Dowel
21 Gear Case Dowel
22 Eye Bolt 1/2-13 X .75"LG 304
Notes:
* Recommended spare part
1. See "Universal Twin Screw Seal Parts" on page 113.
POA: Contact customer service for part number.
06/2017

130-UTS Parts

QTY PER
95-03141
PART NO.
PUMP
8 108371+
1 POA
137430+
1
137428+
137429+
2 101806+
E70227
2 V70227
K70227
2 101693+
E70119
2 V70119
K70119
137371+
1 136798+
137373+
137370+
1 136797+
137372+
2 POA
2 132089+
1 137003+
1 137002+
1 CD0116100
1 CD0116000
1 POA
1 POA
6 30-243
8 137070+
1 124584+
1 124586+
3 30-721
PL5060-CH143
Parts List
NOTES
1
Page 105
