SPX FLOW Universal TS Series Instruction Manual page 71

Waukesha Cherry-Burrell Brand Universal TS Series
Figure 170 - Place key in keyway
Figure 171 - Tap key into keyway
Figure 172 - Position key
06/2017
34. Drive shaft only: Place the key in the keyway on the shaft.
35. Drive shaft only: Tap the key in with a hammer.
36. Drive shaft only: Position the key so that it is angled down
slightly toward the end of the shaft (toward the threads). This
aids in installing the gear over the key.
95-03141
Maintenance
Page 69
