Pump Model Oil Capacity
015-UTS 110 ml
030-UTS 216 ml
130-UTS 525 ml
220-UTS 1575 ml
* Aggressive washdown or extreme running conditions may require more frequent intervals.
For more information, see "Lubrication" on page 26.
Pump Model
015-UTS
030-UTS
130-UTS
220-UTS
Pump Model
015-UTS
030-UTS
130-UTS
220-UTS
Pump Model
015-UTS
030-UTS
130-UTS, 220-UTS
06/2017
Reference Tables
Standard: Synthetic Mobil SHC 629-150,
Food Grade: Synthetic Mobil SHC Cibus-150,
Torque Values - Locknuts
Screw Nut Cover Nut
12 ft-lb 7 ft-lb
16 N·m 10 N·m
38 ft-lb 11 ft-lb
52 N·m 15 N·m
88 ft-lb 25 ft-lb
119 N·m 34 N·m
200 ft-lb 55 ft-lb
271 N·m 75 N·m
Torque Values - Gear Case
Bearing Retainer Screws
24 in-lb (2 ft-lb)
3 N·m
84 in-lb (7 ft-lb)
9 N·m
180 in-lb (15 ft-lb)
20 N·m
300 in-lb (25 ft-lb)
34 N·m
Torque Values - Locking Assembly
Screw Hex Size
5 mm
5 mm
6 mm
95-03141
Oil
part no. 139215+
part no. 139684+
Screw Nut
15/16"
1-1/4"
1-5/8"
2-1/4"
Gear Case Cover Fasteners
Locking Nut
15 ft-lb
20 N·m
30 ft-lb
41 N·m
45 ft-lb
61 N·m
75 ft-lb
102 N·m
Qty. Half Torque
63 in-lb
8
7 N·m
79 in-lb
6
9 N·m
189 in-lb
6
21 N·m
Maintenance
Change oil
250 hours, every
2000 hours
thereafter*
Wrench Size
Cover Nut
5/8"
7/8"
HHCS SHSB
88 in-lb 110 in-lb
10 N·m 12 N·m
110 in-lb 132 in-lb
12 N·m 15 N·m
132 in-lb 176 in-lb
15 N·m 20 N·m
Full Torque
126 in-lb
14 N·m
158 in-lb
18 N·m
378 in-lb
43 N·m
